Overview
The Pass & Seymour PSL615-C is an industrial specification-grade Turnlok locking connector designed for secure, reliable electrical connections in harsh jobsite conditions. This 2-pole 3-wire connector is rated for 15 amps and 250 volts AC, meeting NEMA L6-15R standards. The durable nylon 6/6 shell is impact- and corrosion-resistant, making it suitable for industrial and commercial applications where reliability is critical.
Key Features
- Industrial-strength brass alloy plug blades and connector contacts resist heat rise and provide excellent conductivity
- Raised ribs provide non-slip gripping profile for turning to lock and unlock
- Double dovetail design provides superior protection against cord pull-out forces
- Quick-thread assembly screws and cord-grip screws come backed-out, ready-to-wire
- Rounded back contour reduces snags and hang-ups on the job site
- Visible stamped NEMA configuration and external cord grips provide assurance of safe and proper cord retention
Technical Specifications
The PSL615-C is engineered for demanding industrial service with precise electrical and mechanical ratings:
- Accepts conductors of size 18–10 AWG and cords of size 0.23–0.72 inch
- Dimensions: 1.516 inch diameter × 2.589 inch length
- Withstands 1600 volts minimum dielectric strength
- Operating temperature range: −40 to 75°C; IP20 degree of protection against ingress of solid objects
- RoHS compliant
Typical Applications
The Pass & Seymour PSL615-C is commonly deployed in:
- Industrial equipment and machinery requiring 250V three-phase or single-phase power connections
- Construction and portable equipment with extra-hard use (EHU) environmental requirements
- Jobsite temporary power distribution and extension cord assemblies
- Commercial HVAC, welding, and process control systems operating at 250V
- Any application where a secure, locking connector prevents accidental disconnection
Compatibility & Replacements
Compatible With
- Any NEMA L6-15R receptacle or inlet rated for 15A, 250V operation
- Industrial specification-grade power cables and cord assemblies (18–10 AWG)
- Three-wire power systems requiring 2-pole, 3-wire configuration
- Heavy-duty outdoor and job-site temporary power systems
Replaces / Drop-In Replacement For
- Equivalent NEMA L6-15R industrial locking connectors from other manufacturers
- Other Pass & Seymour Turnlok L6-15R connector models with same voltage and amperage ratings
- Verify exact compatibility with your equipment manufacturer before ordering to ensure proper fit and performance
Works With
- Any NEMA L6-15R inlet or receptacle system
- Industrial power distribution systems operating at 250V
- Locking connector-based power cord and cable assemblies
- Jobsite power management and temporary distribution equipment
