Overview
The Parker 932670Q is a premium replacement hydraulic filter element engineered for the Parker 50P high-pressure inline filter series. This cartridge delivers consistent 10 micron filtration using advanced Microglass III media, protecting hydraulic systems from particulate contamination across a wide range of industrial and mobile applications. Built to SAE HF4 automotive standards, the 932670Q is a direct replacement that maintains OEM performance at competitive pricing.
Key Features
- 10 Micron Filtration: Beta 1000 efficiency at 12.4 microns ensures superior contaminant removal
- Microglass III Media: Multi-layer glass fiber construction with optimized differential pressure and extended service life
- Double Open End Design: Fits standard 50P series bowls without modification
- High Dirt Capacity: >92.2 grams capacity at 7 bar terminal pressure drop (ISO16889 tested)
- SAE HF4 Compliant: Meets automotive and industrial filtration standards
- Fluorocarbon Seals: Viton gaskets for compatibility with mineral and synthetic fluids
Technical Specifications
- Micron Rating: 10 microns
- Beta Rating: >1000 @ 12.4 microns
- Outer Diameter: 99 mm (3.9 inches)
- Length: 235 mm (9.25 inches)
- Inner Diameter (Top/Bottom): 42 mm
- Seal Material: Fluoroelastomer (Viton)
- Filter Media: Multilayer Microglass with coated mesh
- Maximum Operating Pressure: 10 bar (145 psi)
- Collapse Pressure: >10 bar (>145 psi)
- Maximum Temperature: 248°F (120°C)
- Differential Pressure @ 1000 L/min: 0.51 bar (7.4 psi)
- Flow Direction: Outside-to-inside
- Configuration: Double open end
- Dirt Holding Capacity: >92.2 grams @ 7 bar terminal drop
- Filter Area: 790 sq. inches
Typical Applications
The Parker 932670Q serves critical filtration needs in:
- High-pressure hydraulic systems in industrial machinery and processing equipment
- Mobile equipment filtration (heavy equipment, agricultural, construction)
- Automotive transmission and lubrication circuits
- Pump protection in bearing-intensive applications
- Fluid conditioning systems for hydraulic, mineral oil, and synthetic fluids
Compatibility & Replacements
Compatible With
- Parker 50P high-pressure inline filter series
- Parker ParFit Interchange systems
- Single-length bowl assemblies rated for 10 micron filtration
- Hydraulic systems operating at 10 bar maximum pressure
- Mineral and synthetic hydraulic fluids with fluoroelastomer compatibility
Replaces / Drop-In Replacement For
- Parker original equipment 932670Q
- Pall HC9700FKS9H equivalent (OEM crossover)
- Direct replacement for ParFit interchange applications
- Equivalent replacement filters from SONA, Filtration Point, and other aftermarket suppliers follow same dimensions and performance specifications
Works With
- Parker 50P filter housing assemblies
- Standard SAE HF4 hydraulic filtration protocols
- ISO 3968 performance testing standards
- ISO16889 multi-pass efficiency verification
- Industrial hydraulic system designs rated for 10 bar differential pressure
