Overview
The Hubbell OMNI-US2000 is a low-voltage ceiling-mounted occupancy sensor that uses ultrasonic technology to control lighting and HVAC based on space occupancy. These sensors employ ultrasonic technology to turn lighting on and off based on occupancy, and are designed to provide accurate turn-on while virtually eliminating false-offs. The sensor provides 24 VDC operation with 2000 sq-ft coverage and is designed for ceiling and surface mounting.
Key Features
- IntelliDAPT® Technology: Hubbell’s patented IntelliDAPT technology automatically adjusts sensor settings, with smart software that analyzes the controlled area and makes digital adjustments to sensitivity and timer settings throughout the product’s lifespan.
- Maintenance-Free Operation: Occupancy sensors with IntelliDAPT provide a maintenance-free “Install and Forget” operation.
- Self-Adjusting Timer: The auto mode is self-adjustable based on occupancy from 8 to 30 minutes.
- Robust Construction: Features rugged casing with high-impact injection molded plastic KJB ABS construction and Fresnel lens.
- Optional Relay Control: Optional relay control is available for use with building automation systems and a photo sensor for automatic daylight harvesting.
- Dual-Element Detection: Features a dual-element pyrometer and 12-element cylindrical rugged lens.
Technical Specifications
- Supply Voltage: 24 Volt DC
- Current Draw: 33 milliamps
- Coverage Area: 2000 square feet
- Response Frequency: 32 kHz response
- Time Delay Modes: 8–30 minutes in automatic mode and 8 seconds in test mode
- Operating Temperature: 32 to 104 degrees Fahrenheit (0 to 40 degrees Celsius)
- Humidity: Less than 95 percent relative humidity, non-condensing
- Dimensions: 4.5 by 1.5 inches diameter
- Recommended Mounting Height: 8 to 12 feet ceiling mount
- Wiring: 6-inch long color-coded lead terminal connection
- Material: White finish, UV-inhibited ABS plastic
- Memory: Non-volatile memory saves learned and adjusted settings in protected memory
Typical Applications
The OMNI-US2000 is designed specifically for both areas with obstructions and areas with long periods of minor motion activity. Common installations include:
- Office spaces, conference rooms, and boardrooms
- Storage and utility rooms
- Low-traffic areas requiring accurate occupancy detection
- Building automation and energy management systems
- Facilities requiring maintenance-free lighting control
Compatibility & Replacements
Compatible With
- 24 VDC low-voltage power supplies and control systems
- Building automation and lighting control systems
- Hubbell power packs and relay modules
- Standard electrical junction boxes for ceiling mounting
- Energy management systems requiring occupancy input
Replaces / Drop-In Replacement For
The OMNI-US2000 is directly compatible with Hubbell OMNI family sensors in the same 2000 sq-ft coverage class and low-voltage 24 VDC specification. Verify compatibility with your system integrator before ordering.
Works With
- Hubbell power packs (PP series, MP series, UVPP models)
- Building management systems with occupancy input
- Lighting control networks and relay modules
- 24 VDC control circuits and automation logic
