Overview
The NTE R10-14A10-120N relay is a robust electromechanical switching device designed for general purpose control applications in industrial and commercial systems. With a 120VAC coil, 3PDT contact configuration, and 10-amp contact rating, this relay delivers reliable switching performance across AC and DC loads. The large ice cube form factor and quick-connect 0.187″ terminals make installation straightforward in standard relay sockets.
Key Features
- 3PDT (3-pole, double-throw) contact configuration for flexible load control
- 120VAC coil voltage with wide contact voltage range (240V AC, 28V DC)
- 10A contact current rating at rated voltages
- Large ice cube (11-pin) plug-in socket mounting
- 0.187″ quick-connect terminals with solder hole option
- Integrated indicator lamp for visual coil status
- RoHS-compliant construction
Technical Specifications
- Coil Voltage: 120VAC
- Contact Configuration: 3PDT
- Contact Current Rating: 10A @ 120V/240V AC; 10A @ 28V DC
- Contact Voltage (AC): 240V maximum
- Contact Voltage (DC): 28V maximum
- Terminals: 0.187″ (4.75mm) quick-connect blade with solder holes
- Mounting Style: 11-pin large ice cube plug-in socket
- Indicator Lamp: Yes, included
- Dimensions: 38.89 x 35.72 x 55.56 mm
- RoHS Compliant: Yes
- Series: NTE R10 General Purpose Relays
Typical Applications
- HVAC control circuits and fan motor switching
- Pump and compressor start/stop control
- Lighting and load management in industrial panels
- Machine tool interlocking and safety circuits
- Process automation and equipment sequencing
- General-purpose switching in 120VAC control systems
Compatibility & Replacements
Compatible With
- Standard 11-pin large ice cube relay sockets
- 120VAC control circuits and contactors
- Industrial control panels and motor starters
- HVAC and refrigeration control systems
- General-purpose automation and switching applications
Replaces / Drop-In Replacement For
- Equivalent 3PDT, 10A, 120VAC relays in large ice cube form factor
- Original equipment manufacturer (OEM) relays requiring similar specifications
- Verify exact compatibility with your system integrator before ordering
Works With
- 120VAC power supply and control circuits
- Standard relay sockets and DIN rail mounting panels
- Contactor and soft-starter control systems
- Discrete wiring and hardwired control systems (non-PLC)
