Overview
The Norgren 18-015-207 is a direct-reading pneumatic pressure gauge engineered for accurate monitoring of low-pressure pneumatic systems. This gauge delivers reliable performance across general industrial applications where precise pressure indication is critical for system safety and efficiency. Built to Norgren standards, it integrates seamlessly into pneumatic circuits and test stations.
Key Features
- 0–30 PSI measurement range with simultaneous bar and MPa scales for multi-standard operations
- 1/4 NPT male threaded port for direct mounting into standard pneumatic manifolds and tees
- 2-inch (50 mm) glycerin-filled dial face for clear visibility and shock resistance
- Durable ABS housing with thermoplastic window for long service life in shop floors and control panels
- Center black needle pointer for easy, precise reading across all pressure ranges
Technical Specifications
The Norgren 18-015-207 pressure gauge is part of the 18-015 series, a proven family of industrial pressure instruments. It provides stable, repeatable readings suitable for pneumatic system commissioning, maintenance, and troubleshooting.
Typical Applications
- Pneumatic control circuit pressure monitoring
- Air compressor discharge line verification
- Pneumatic actuator circuit diagnostics
- System commissioning and performance testing
- Maintenance troubleshooting and pressure validation
- Machine tool and automation equipment instrumentation
Compatibility & Replacements
Compatible With
- Norgren pneumatic manifolds and distribution blocks
- Standard 1/4 NPT male thread pneumatic circuits
- Compressed air systems 0–30 PSI nominal operating range
- Industrial control panels and test benches
- ISO 4414 pneumatic system standards
Replaces / Drop-In Replacement For
- Norgren 18-015-201 (1/8 NPT equivalent in 0–30 PSI range)
- Other direct 0–30 PSI Norgren gauges with 1/4 NPT threading
Works With
- Norgren air preparation units, regulators, and filter assemblies
- Any ISO 4414 compliant pneumatic component with 1/4 NPT ports
- Compressed air systems from 0–30 PSI operating envelope
