Overview
The Nidec V35132-16LRCKF is a precision-engineered brushless DC cooling fan designed for demanding thermal management applications. Operating at 24VDC, this model combines advanced motor technology with robust mechanical design to deliver consistent airflow in high-density server, industrial control, and telecommunications environments. Built to withstand continuous operation, the V35132-16LRCKF is ideal for OEMs and maintenance engineers seeking reliable replacement cooling solutions.
Key Features
- Brushless DC motor: Reduced friction, minimal wear, extended service life
- Dual ball bearing design: Enhanced durability and vibration resistance for 24/7 operation
- Flame-retardant housing: Compliant with safety standards for critical infrastructure
- Compact 80mm form factor: Easy retrofit into existing server and industrial chassis
- Two-wire terminal: Simple installation with standard power and ground connections
Technical Specifications
Key performance and electrical parameters for system integration:
- Operating Voltage: 24VDC (rated)
- Voltage Range: 14.0–27.6VDC
- Rated Current: Approximately 0.45A at 24VDC
- Input Power: ~11W nominal
- Rated Speed: 4800 RPM
- Bearing Type: Dual ball bearing
- Frame Size: 80 × 80 × 38mm
- Terminal Type: 2-wire (power and ground)
- Motor Type: Brushless DC (BLDC)
Typical Applications
The Nidec V35132-16LRCKF is suited for cooling in:
- Rack-mounted servers and blade enclosures
- Industrial automation control panels and frequency converters
- Telecommunications base station equipment
- Medical instrumentation and diagnostic systems
- Power supply units and industrial power electronics
- High-density electronic equipment requiring sustained airflow
Compatibility & Replacements
Compatible With
- 24VDC power supplies (14–27.6V operating range)
- Server chassis and rack-mount enclosures with 80mm fan bays
- Industrial control systems and frequency converter modules
- Custom thermal management assemblies requiring brushless DC motors
Replaces / Drop-In Replacement For
- Nidec V35132-16F (direct equivalent variant)
- Other 80×80×38mm, 24VDC, 2-wire cooling fans in server and industrial applications
Works With
- Any system utilizing standard 24VDC power distribution
- Direct DC power control (PWM-capable if controller supports variable voltage)
- Thermal management controllers and monitoring systems with 24VDC fan interfaces
