Overview
The Newport P6000 is a versatile programmable counter and frequency meter designed for industrial process measurement and control applications. As a multifunction instrument, the P6000 combines five operating modes with microprocessor-based configuration, non-volatile memory storage, and RS-232 connectivity for seamless integration into automation systems.
Key Features
- Five operating modes: frequency meter, tachometer, frequency-ratio meter, period/period-average meter, time interval/time-interval-average meter, and totalizer
- Microprocessor-based design with menu-driven front-panel programming
- Program storage in non-volatile memory with four-level security lockout
- RS-232 interface for PC-based programming and real-time monitoring
- Fixed decimal point or auto-ranging display options
- Class II safety protection per IEC 348 and VDE 0411
Technical Specifications
The P6000 supports dynamic frequency measurement across a wide range with six-figure crystal-based accuracy. The unit features 24V regulated excitation voltage (25 mA maximum) on dedicated terminals for sensor conditioning. Front-panel pushbutton interface allows scrollable navigation through functions and settings. The instrument operates without a power-on switch, requiring isolation from the AC/DC supply to power down.
Typical Applications
- Production line counters and event tallies
- Speed and tachometer measurement (frequency conversion to RPM)
- Frequency and time-interval monitoring
- Process cycle rate and period measurement
- Totalizer accumulation for cumulative counts
- Period averaging for noise-immune frequency measurement
Compatibility & Replacements
Compatible With
- PLC and automation control systems requiring process measurement inputs
- Legacy industrial measurement and control networks
- Systems with RS-232 serial communication interfaces
Replaces / Drop-In Replacement For
- Newport P6000A (same mechanical and electrical form factor)
- Newport P5000 (variant sharing compatible input modules)
Works With
- RS-232 serial interface for PC programming and data logging
- Front-panel pushbutton configuration (no additional software required)
- Legacy industrial automation systems
