Overview
The Motorola M68MM01A2 is a monoboard microcomputer circuit board designed as a self-contained micromodule within Motorola’s classic microcomputer platform. This unit carries revision designations 84DW6736X01 Rev S and 01DW1736X01 Rev AR, indicating it has been manufactured and tested to Motorola’s original specifications. As a legacy component, the M68MM01A2 remains valued in embedded systems restoration, educational projects, and retro-computing applications where original Motorola hardware is required.
Key Features
- Authentic Motorola micromodule design with dual revision markings (Rev S and Rev AR)
- Self-contained monoboard architecture for independent operation or system integration
- Original component layout and specifications maintained without modification
- Suitable for legacy system reconstruction and development board applications
- Part of Motorola’s established microcomputer product line with historical documentation support
Technical Specifications
Detailed technical specifications for this legacy component are available upon request or through direct consultation with Motorola historical documentation. The board is identified by the following revision and model numbers:
- Primary Part Number: 84DW6736X01 Rev S
- Secondary Designation: 01DW1736X01 Rev AR
- Model: Monoboard Microcomputer 1A/1A2 Micromodule 1A/1A2
- Condition: Used, fully functional
- Type: Printed Circuit Board (PCB)
Typical Applications
The Motorola M68MM01A2 is commonly used in the following scenarios:
- Restoration and repair of vintage Motorola microcomputer systems
- Educational demonstrations of classic microprocessor architecture
- Embedded systems using legacy Motorola 68xx series processors
- Development and prototyping platforms for retro-computing projects
- Original equipment replacement in industrial control systems from the 1970s–1980s era
Compatibility & Replacements
Compatible With
- Motorola microcomputer development systems
- Motorola EXORCISER evaluation platform
- Classic embedded control applications using 68xx-series processors
- Educational and training environments for microcomputer fundamentals
Replaces / Drop-In Replacement For
This unit is a direct replacement for original Motorola M68MM01A2 boards bearing equivalent revision codes. Verify compatibility with your specific system integrator or Motorola technical support before ordering to ensure application fit.
Works With
- Motorola 68000 and 68010 microprocessor families
- Classic parallel and serial I/O interfaces
- Motorola development tools and monitor programs (JBUG, TUTOR, MIKBUG)
- Wire-wrap and custom circuit expansion areas for system customization
