Overview
The Molex 19212-0013 is an InsulKrimp wire pin terminal designed for secure, reliable connections in industrial and commercial electrical applications. Rated for 12-10 AWG wire with a 600V voltage rating, this terminal features a 9/32″ pin size and crimp-style termination suitable for use with European-style terminal blocks and component connections.
Key Features
- Crimp termination for 12-10 AWG stranded and solid wire
- 600V voltage rating for industrial power distribution
- Insulated sleeve prevents vibration damage and wire flex
- Prevents wire strand foldback for stronger, more reliable connections
- Copper contact with tin plating for corrosion resistance
- Compatible with European-style terminal blocks and clamping systems
Technical Specifications
- Part Number: 19212-0013 / 192120013
- Series: InsulKrimp 19212
- Wire Size Range: 12-10 AWG
- Voltage Rating: 600V
- Pin Diameter: 9/32″ (approx. 7.14 mm)
- Termination Type: Crimp
- Contact Material: Copper
- Contact Plating: Tin
- Insulation: Polyamide (Nylon)
- Compliance: EU RoHS, IEC 62474, Low-Halogen
Typical Applications
- European-style terminal block connections
- Industrial control panel wiring
- Power distribution circuits
- Equipment and machinery electrical connections
- Automotive and transportation electrical systems
- HVAC and mechanical systems wiring
Compatibility & Replacements
Compatible With
- European-style terminal blocks
- Clamp and set-screw connection systems
- Industrial control equipment
- Electrical components with 9/32″ receptacles
Replaces / Drop-In Replacement For
- Other 12-10 AWG wire pin terminals with 9/32″ pin diameter and 600V rating
Works With
- Standard crimp tools compatible with 9/32″ pins
- Terminal block assemblies rated for 600V
- Industrial automation and control systems
