Overview
The Minco S884 PE120Z24(C) slip tip assembly is a precision temperature sensing element engineered for industrial automation and motion control systems. This RTD (Resistance Temperature Detector) assembly features a slip tip design that enables installation into tight bore holes and restricted spaces where standard sensors cannot fit. The slip tip mechanism provides secure, spring-loaded contact with minimal response time, making it ideal for accurate thermal monitoring in machinery, equipment bearings, and process control applications.
Key Features
- Slip tip design for installation in drilled holes and confined spaces
- Spring-loaded contact mechanism ensures reliable sensor positioning
- Compact form factor suitable for tight automation and mechanical assemblies
- Precision RTD element for fast thermal response
- Durable construction for harsh industrial environments
- New condition, open box availability
Technical Specifications
The following specifications apply to this Minco RTD assembly:
- Manufacturer: Minco Products
- Series: S884 Tip-Sensitive RTD
- Part Number: PE120Z24(C)
- Assembly Type: Slip Tip / Spring-Loaded
- Sensing Element: RTD (Platinum resistance thermometer)
- Typical Temperature Range: -50 to 260°C (-58 to 500°F)
- Response Time: Fast response for dynamic temperature monitoring
- Installation Method: Spring-loaded slip tip for bore hole mounting
- Housing Material: Stainless steel or protective alloy
- Built-in Protection: Oil seal for bearing and tight-space applications
Typical Applications
The Minco S884 PE120Z24(C) slip tip assembly is commonly used in:
- Bearing temperature monitoring on rotating machinery
- Electric motor thermal protection and condition monitoring
- Gearbox and drivetrain temperature measurement
- Industrial pumps and compressor thermal feedback
- CNC and automation equipment bearing monitoring
- Process control and thermal management systems
Compatibility & Replacements
Compatible With
- Minco transmitters and signal conditioning modules
- Industrial temperature monitoring and control systems
- RTD-compatible data acquisition systems
- HART-enabled monitoring equipment
- Standard PLC analog input modules (with appropriate transmitter)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or technical support before ordering, as RTD assembly replacements depend on specific connection type, lead configuration, and transmitter requirements.
Works With
- Minco RTD transmitters (4–20 mA output)
- Minco controllers and temperature monitors
- Industrial automation platforms with analog RTD input capability
- Standard resistance measurement equipment
- Thermal management and condition monitoring software
