Overview
The MGE Pulsar EXB10 is an extended battery module designed to provide backup power for Pulsar EX10 uninterruptible power supply (UPS) systems. This battery pack consists of six sealed lead-acid batteries configured in series to deliver 36 volts DC output, making it ideal for mission-critical industrial automation and control applications where power continuity is essential.
Key Features
- 36Vdc output: Six 12V 7.5Ah batteries configured for industrial-grade voltage
- AGM sealed battery technology: Absorption Glass Mat construction ensures safe, maintenance-free operation
- High-rate discharge: Optimized for UPS applications requiring rapid power delivery during utility power loss
- UL certified: Meets safety standards for power backup systems
- F2 terminals: Standard connectors compatible with original Pulsar EX10 cabling and hardware
- 3–5 year lifespan: Typical service life for AGM UPS batteries under normal operating conditions
Technical Specifications
- Output Voltage: 36Vdc (six 12V cells in series)
- Capacity per Cell: 7.5Ah (12V nominal)
- Total Pack Capacity: 7.5Ah at 36Vdc
- Battery Type: Sealed Lead-Acid (AGM)
- Terminal Type: F2 (0.250″ spade connector)
- Number of Cells: 6 (12V modules)
- Individual Cell Dimensions (approx.): 151 mm L × 65 mm W × 94 mm H
- Individual Cell Weight: 4.97 lbs per cell (approx. 30 lbs total pack)
- Operating Temperature: 0°C to 40°C (standard for sealed lead-acid)
- Certifications: UL, CE marked
- Warranty: 1 year standard; extended warranties available
Typical Applications
- Extended runtime for industrial UPS systems protecting PLC and automation controllers
- Data center and server room backup power
- Mission-critical control system continuity during mains power interruption
- Gateway and communications equipment protection in remote installations
- Emergency lighting and safety system backup
Compatibility & Replacements
Compatible With
- Pulsar EX10 UPS system
- Standard 36Vdc sealed lead-acid battery architectures
- Industrial automation systems requiring AGM battery backup
- Original Pulsar EX10 mounting rails and cable harnesses
Replaces / Drop-In Replacement For
- Original MGE/Eaton Pulsar EXB10 battery pack
- Equivalent six-cell 36Vdc sealed lead-acid battery cartridges with F2 terminals
- Verify compatibility with your system integrator before ordering
Works With
- Pulsar EX10 and related Eaton/MGE UPS platforms
- Standard industrial-grade sealed lead-acid charging circuitry
- UPS management software and monitoring systems communicating with Pulsar controllers
- Existing Pulsar EX10 battery enclosures and thermal management systems
