Overview
The Lutron N-600-IV is an architectural-style incandescent dimmer designed for reliable residential and commercial lighting control. This single-pole dimmer switches and dims 600W incandescent or halogen loads at 120VAC, 60Hz. The slide-to-off operation offers intuitive brightness adjustment from full off to full brightness, with a captive linear slider that moves smoothly in both directions.
Key Features
- Square Law dimming for natural light transitions
- Voltage compensation maintains stable light levels despite line voltage variations
- Power failure memory retains brightness setting after power outages
- Superior RFI (radio frequency interference) suppression prevents signal disruption
- Captive linear slider with accessible air gap switch for safety
- Electrostatic discharge tested for reliability
- Heavy-duty components provide surge protection and extended product life
- Matte ivory finish with architectural wallplate design (included)
Technical Specifications
- Load Type: Incandescent/Halogen lamps
- Load Capacity: 600W maximum
- Voltage Rating: 120VAC at 60Hz
- Operation Type: 1-Pole, slide-to-off
- Control Method: Linear slide (captive slider)
- Mounting: Standard wallbox, 1-gang
- Dimensions: 4.56 in H × 2.75 in W × 1.31 in D
- Finish: Matte ivory
- Operating Temperature: 0–40°C (32–104°F)
- Certifications: UL 1472, CSA C22.2 184.1, NOM, ANSI/IEEE C62.41-1980
- Warranty: 1-Year Limited
- Wall Plate: 1-Gang architectural (included)
Typical Applications
- Residential lighting control in living rooms, bedrooms, dining areas
- Commercial office and retail lighting management
- Dimming incandescent and halogen track lights
- Accent lighting in hospitality environments
- Any standard wallbox installation where 600W incandescent load control is required
Compatibility & Replacements
Compatible With
- Standard North American 120VAC 60Hz electrical systems
- Incandescent and halogen lamp fixtures rated for dimming
- Lutron Nova family of control devices and matching wallplates
- Standard single-gang wallbox installations
Replaces / Drop-In Replacement For
- Lutron N-600-WH (white variant — functional equivalent in white finish)
- Lutron N-600 series incandescent dimmers in ivory
Works With
- Lutron Nova architectural wallplate family
- Standard residential and commercial 120VAC circuits
- Incandescent and halogen loads only (not compatible with LED or CFL without external drivers)
