Overview
The Lenord + Bauer GEL2444TN1R3K150 is a compact incremental rotary encoder engineered for demanding motion control and industrial automation applications. This MiniCODER model combines magnetoresistive sensing technology with TTL-compatible output signals to deliver accurate speed and position feedback in machinery, drive systems, and control applications. The TN signal pattern provides TTL level outputs suitable for digital control systems and PLCs.
Key Features
- Magnetoresistive contactless sensing technology for reliable operation without mechanical wear
- TTL output signals (TN pattern) compatible with standard industrial controllers
- 90° offset quadrature square-wave signals with inverse signals and short-circuit protection
- Compact MiniCODER design suitable for confined installation spaces
- 1.5-meter flying lead cable (K150 designation) for easy integration
- Suitable for high-speed motion feedback and encoder-driven control systems
Technical Specifications
- Signal Pattern: TN (TTL output levels)
- Output Type: Two 90° offset square-wave signals with inverse signals
- Output Protection: Short-circuit proof
- Cable Length: 1.5 meters (flying leads)
- Technology: Magnetoresistive scanning
- Reference Signal: Optional
- Design: Compact MiniCODER form factor
Typical Applications
- Motor speed feedback and tachometer functions
- Shaft position and rotation detection
- Drive system commissioning and tuning
- Machinery speed monitoring and control
- Position-based control in automated equipment
- Industrial process monitoring where space is limited
Compatibility & Replacements
Compatible With
- Allen-Bradley PLCs and controllers with TTL input modules
- Siemens S7 series controllers with digital input cards
- Mitsubishi, Omron, and other industrial control systems supporting TTL encoder inputs
- Standard incremental encoder input modules across major automation platforms
- DC drives and servo systems with encoder feedback capability
Replaces / Drop-In Replacement For
- Direct replacement for other GEL2444TN1R3K models with 1.5-meter cable specifications
- Interchangeable with similar 2444 series MiniCODER variants with TN output pattern
- Verify compatibility with system integrator for specific application requirements
Works With
- TTL-level encoder input interfaces and modules
- Industrial PLC programming software (Studio 5000, TIA Portal, Mitsubishi GX Works)
- Incremental encoder processing functions in motion control systems
- Drive commissioning tools and diagnostic software supporting encoder feedback
