Overview
The ITT Standard 5-030-05-014-001 is a straight-tube, fixed-tubesheet shell & tube heat exchanger manufactured by Standard Xchange (formerly ITT Standard). This BCF series unit features a 5-inch shell diameter with 14-inch tube length and single-pass tube-side configuration with narrow baffle spacing. It is designed for reliable thermal transfer in industrial heating and cooling applications.
Key Features
- Compact design: 5″ shell diameter with fixed tube bundle for cost-effective installation
- Straight tube construction: Eliminates tube bending stress and facilitates maintenance
- Fixed tubesheet: Lower cost alternative to removable bundle designs
- Narrow baffle spacing (O): Optimizes shellside fluid distribution and heat transfer efficiency
- Single-pass configuration: Straightforward flow pattern for predictable thermal performance
- Brass shell with copper tubes: Excellent corrosion resistance in water and moderate fluid service
Technical Specifications
- Shellside design rating: 300 PSI at 300°F
- Tubeside design rating: 150 PSI at 300°F
- Materials: Brass shell, copper tubes, cast iron bonnets, zinc anodes
- Tube length: 14 inches
- Shell diameter: 5 inches
- Tube passes: 1-pass
- Baffle spacing: O (narrow)
Typical Applications
- Water heating and cooling loops
- Lube oil circulation and conditioning
- Steam condensation
- Auxiliary machinery cooling (turbines, engines, compressors)
- Pilot-scale process systems and experimental apparatus
Compatibility & Replacements
Compatible With
- ASME and TEMA rated shell & tube heat exchanger systems
- Industrial cooling and heating loops with operating pressures up to 300 PSI
- Piping systems using NPT or ANSI flange connections
- Facilities requiring fixed-tubesheet, straight-tube geometry
Replaces / Drop-In Replacement For
- ITT Standard 5-030-05-014-001 (existing units in service)
- Verify exact model compatibility with your system integrator or distributor before ordering
Works With
- Thermosiphon and forced-circulation cooling systems
- Industrial HVAC loops and facility cooling water circuits
- Steam condensate recovery systems
- Any piped heat transfer system rated for 150–300 PSI operation
