Overview
The Hubbell HBL2411 twist-lock plug delivers industrial-grade connectivity for portable power applications. Featuring a ribbed nylon housing that provides a secure grip and impact and chemical resistance, this L14-20P connector is rated for 20A at 125/250V AC with 3-pole 4-wire grounding. A superior cord grip design protects terminations from excess strain and a clear, funnel shaped wire entry makes for ease of termination.
Key Features
- Ribbed nylon Insulgrip housing provides secure grip, impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- Clear, funnel shaped wire entry for ease of termination
- Integral dust shield protects wiring chamber from dust or contaminants
- Screw terminal design for field wiring
- NEMA L14-20P configuration for standard twist-lock receptacles
Technical Specifications
- 20A rated current with 125/250V AC voltage
- Accommodates #16 AWG through #8 AWG stranded copper wire
- Conductor size: 12-10 AWG
- Rated for extra heavy duty industrial applications
- Black and white nylon body
- Cord range: 0.350″-1.150″ (9-29 mm)
- Maximum 2 horsepower rating
- CSA C22.2 No.42, Federal Specification W-C-596, UL 498 certified
Typical Applications
The HBL2411 is designed for portable cord applications in industrial environments including temporary job site power distribution, industrial equipment connections, and heavy-duty portable loads requiring grounded power. Suitable for indoor use unless protected by additional weathering means. Commonly specified for equipment rated 2 hp or less at the indicated amperage.
Compatibility & Replacements
Compatible With
- NEMA L14-20R receptacles (standard twist-lock inlet)
- Industrial twist-lock power distribution systems
- Equipment and cord sets rated L14-20P
- 20A, 125/250V portable power circuits
Replaces / Drop-In Replacement For
The Hubbell HBL2411 is the direct replacement for any OEM or surplus L14-20P twist-lock plug application requiring 20A, 125/250V capability with Insulgrip construction. Verify connector orientation and wire gauge compatibility before installation.
Works With
- Portable power cords and cable assemblies
- Industrial extension cord sets
- Equipment with L14-20R inlet connections
- Temporary power distribution panels
