Overview
The Hoffman F88L06 is a lay-in NEMA Type 12 wireway straight section measuring 8 inches (height) × 8 inches (width) × 6 inches (length). Manufactured by nVent Hoffman, this gasketed, hinged-cover wireway is engineered for industrial applications requiring protection of wiring and cables against exposure to oil, coolant, and other environmental contaminants.
Key Features
- NEMA Type 12 rated for oil and dust protection
- Gasketed hinged cover with quick-release latches for easy access
- Open-side lay-in design—wires and cables lay in without pulling through
- 14 gauge steel construction with ANSI 61 gray polyester powder finish
- No knockouts; mounting-ready straight section
- Available in standard 6-inch length; extendable system with compatible fittings
Technical Specifications
- Height: 8 inches
- Width: 8 inches
- Length: 6 inches
- Material: 14 gauge steel
- Finish: ANSI 61 gray polyester powder coat
- Cover Type: Hinged with gasketed seal
- Knockouts: None
- NEMA Rating: Type 12 (oil-tight, dust-tight)
- Mounting: Wall or ceiling mounted
- Cross Reference: 19160
Typical Applications
The Hoffman F88L06 wireway is ideal for:
- Machine tool installations where coolant spray and mist are present
- Manufacturing floor distribution of control and power wiring
- Automotive and metalworking facility wiring runs
- Industrial enclosure cable management and branch circuit protection
- Areas requiring NEMA Type 12 environmental protection
Compatibility & Replacements
Compatible With
- nVent Hoffman wireway duct system components (all 8×8 series)
- Standard industrial electrical installation practices (NEMA/UL listed)
- Wall and ceiling mounting infrastructure
- Low-voltage and power distribution circuits
Replaces / Drop-In Replacement For
- Cross reference 19160 (alternative part numbering)
- Compatible with other 8x8x6 lay-in wireway configurations from nVent Hoffman
Works With
- Hoffman wireway tees, elbows, and end plates
- Standard U-connectors and junction fittings
- Gasketed cover hardware and latches
- Industrial cable trays and support systems
