Overview
The Hoffman VC1516012 is a compressed air vortex cooler designed for industrial enclosure cooling applications. Powered by compressed air, this cooler generates chilled air to maintain optimal temperatures in small control enclosures, electrical cabinets, and junction boxes without using refrigerants or moving parts. The aluminum construction with brushed finish and NEMA Type 12 rating provides durability in harsh and outdoor environments.
Key Features
- Cooling capacity of 1500 BTU/hour for compact enclosures
- Powered by compressed air—no electricity needed for cooling function
- Aluminum construction with brushed finish and NEMA Type 12 rating
- Five-micron airline filter and 115 V solenoid included
- Ducting kit included for easy installation
- Thermostat control for automatic temperature management
- Low maintenance and reliable in harsh, dusty environments
Technical Specifications
- Cooling Capacity: 1500 BTU/hour
- Power Rating: 440 Watts (for solenoid and controls)
- Voltage: 115V AC, 50/60 Hz
- Compressed Air Consumption: 25 SCFM
- Enclosure Rating: NEMA Type 12
- Material: Aluminum with brushed finish
- Control Type: Thermostat
- Noise Level: 83 dB
- Height: 10.75 inches (273 mm)
- Weight: 6 pounds (2.72 kg)
- Certifications: UL508 Listed (Type 12), cUL Listed
Typical Applications
- PLC and servo drive enclosures
- Electrical control cabinets in manufacturing plants
- Industrial HVAC and refrigeration equipment housings
- Indoor and outdoor equipment cooling
- Power distribution and control systems
Compatibility & Replacements
Compatible With
- Any facility with 115V AC power and compressed air supply (25 SCFM minimum)
- Control enclosures rated NEMA Type 12 or equivalent
- Standard airline connections with five-micron filtration
- Indoor and outdoor control environments
Replaces / Drop-In Replacement For
The Hoffman VC1516012 is a factory replacement and direct equivalent for cooling applications requiring 1500 BTU/hour capacity. Verify compatibility with your enclosure type and available compressed air supply before ordering.
Works With
- Standard pneumatic airline systems (50/60 Hz)
- Compressed air distribution networks
- Thermostat-based temperature control systems
- NEMA Type 4, 4X, and Type 12 enclosures when properly installed
