Overview
The Harting HAN-10E-STI-S 09330102601 is a male insert connector from Harting’s Han® E series, designed for industrial environments where safe, removable electrical connections are essential. This 10-position + PE connector delivers reliable performance in control cabinets, machinery, and automation systems. The Han E series is engineered to meet the demands of harsh industrial applications with durable construction and proven field reliability.
Key Features
- 10-Position + PE Configuration: 10 contacts + PE, enabling multi-circuit applications
- Screw-Terminal Connection: Wire cross sectional area up to 2.5 mm², accommodating 14–18 AWG conductors
- Industrial Rating: 500 V rated voltage, 16 A rated current
- Proven Han® Series Design: Suited for safe and removable electrical connections in protected electrical areas and outdoor applications
- Male Insert/Stecker Configuration: Direct replacement for existing Han 10E socket housings
Technical Specifications
Series: Han E®, Termination method: Screw
- Contact Count: 10 + PE
- Rated Voltage: 500 V AC/DC
- Rated Current: 16 A per contact
- Wire Cross-Section: Up to 2.5 mm² (14–18 AWG)
- Terminal Type: Screw terminal (DIN screw)
- Part Number: 09330102601
- Series/Family: Han E (Han 10B frame)
- Contact Gender: Male insert (Stecker)
- Material: Engineering plastic housing
- Approvals: Industrial connector standard (IP 67 capable in mated pair)
Typical Applications
The Harting HAN-10E-STI-S connector is commonly used in:
- PLC and servo drive control wiring
- Industrial machinery and equipment interconnection
- Control cabinet terminal strips and patch panels
- Automation system field wiring in Class 2 and higher rated circuits
- Multi-position connector replacements in Han E modular systems
Compatibility & Replacements
Compatible With
- Harting Han E series socket housings (female counterparts)
- Han 10B frame size modular systems
- Standard DIN-rail mounted or panel-mount Han E housing configurations
- Industrial control systems using Han connectors
Replaces / Drop-In Replacement For
- Harting HAN-10E-STI-S male inserts across equipment revisions
- Legacy 10-position industrial rectangular connectors in retrofit applications
- OEM Han E 10-pin male inserts on control cabinets and machinery panels
Works With
- Han E modular connector framework and related accessories
- Standard industrial screw-terminal wire gauges (14–18 AWG)
- Control circuit systems operating at 500V or below
- Both AC and DC rated applications (industrial-grade)
