Overview
The Habasit SAW-5E 13 conveyor belt is a premium light-duty belt designed for cross-belt sorters, distribution systems, and material handling applications. This endless belt measures 12mm × 1550mm and features a durable PET fabric with PVC cover and waffle surface finish. The belt is engineered to run cupping-free without V-guides and delivers consistent performance in demanding warehouse and sorting environments.
Key Features
- Endless belt design—no splicing required
- Waffle surface for enhanced grip and stability
- Cupping-free construction proven in cross-belt sorter applications
- Operates without V-guides while maintaining tracking
- Compact 12mm width suits space-constrained installations
- Extended temperature range for diverse operating conditions
Technical Specifications
Construction & Dimensions:
- Width: 12mm
- Length: 1550mm (endless)
- Thickness: 1.8mm
- Belt weight: 1.8 kg/m²
- Surface: Waffle
- Cover material: PVC (anthracite)
- Fabric: PET
Performance Characteristics:
- Tensile force (1% elongation, static): 6.0 N/mm per mm of width
- Tensile force (1% elongation, relaxed): 4.0 N/mm per mm of width
- Coefficient of friction (steel pulley): 0.15
- Coefficient of friction (friction-cover pulley): 0.35
- Min. operating temperature: -5°C (23°F)
- Max. operating temperature: 70°C (158°F)
Typical Applications
The SAW-5E 13 is ideal for:
- Cross-belt sorter (CBS) systems in distribution centers
- Bi-directional conveyor systems
- Lightweight package handling and sorting
- Parcel and document processing
- Warehouse automation and order fulfillment
Compatibility & Replacements
Compatible With
- Cross-belt sorter (CBS) systems from Japanese and European OEMs
- Light-duty material handling conveyors
- Modular conveyor frames designed for 12mm belt width
- Standard pulley systems (minimal V-guide required)
- Warehouse automation and sorting applications
Replaces / Drop-In Replacement For
The SAW-5E 13 12mm × 1550mm can replace worn or damaged belts in existing cross-belt sorter and light-duty conveyor installations. Verify belt routing, pulley sizing, and mounting configuration with your OEM or system integrator before installation.
Works With
- Habasit belt tensioning and tracking systems
- Standard conveyor drive motors and gearboxes
- Slider bed and friction-drive pulley configurations
- Temperature-controlled warehouse environments
- Conveyor management software and PLC control systems
