Overview
The Habasit SAW-5E 13 is a PVC-based light conveyor belt engineered for high-speed sorting, distribution, and material handling applications. With a 12mm width and 1,550mm length, this belt combines durability with precise dimensional consistency. The SAW-5E 13 features anti-static properties and a high-grip surface designed to prevent slippage during demanding operations in parcel sorting, postal facilities, and distribution centers.
Key Features
- 12mm width x 1,550mm length — standard size for compact conveyor systems
- Polyester/PVC composite construction — durable, wear-resistant material
- High-grip surface — superior friction for reliable material transfer
- Anti-static properties — suitable for sensitive electronics and clean environments
- Minimal cupping — maintains flat surface under load without v-guides
- Operating temperature range: -5°C to +50°C (23°F to 122°F)
Technical Specifications
- Thickness: 1.7mm (0.067 inches)
- Material: Polyester core, PVC cover
- Width: 12mm
- Length: 1,550mm
- Minimum pulley diameter: 20.32mm (0.8 inches)
- Operating temperature: -5°C to +50°C
- Weight per unit: 0.014 kg
- Surface finish: High-grip, anti-static
Typical Applications
- Cross-belt sorting systems in distribution centers
- Postal and parcel sorting facilities
- General conveying and transfer belts
- Induction belts for automated material handling
- High-speed sorting and gapping applications
Compatibility & Replacements
Compatible With
- Light-duty conveyor frames and drives
- Standard pulley systems 20mm diameter and larger
- Distribution and sorting automation equipment
- Open-ended belt configurations
Replaces / Drop-In Replacement For
- Verify compatibility with your equipment manufacturer before ordering to ensure proper fit and performance in your specific conveyor system.
Works With
- Horizontal conveyance systems
- Standard conveyor drive motors and gearboxes
- Industry-standard pulley diameters 20mm and above
- Sorting line automation platforms
