Overview
The Goodyear 250XL037 is a standard XL-profile timing belt engineered for industrial and light machinery power transmission. With 125 teeth, 0.37″ width, and 25″ pitch length, this belt delivers positive slip-proof engagement and reliable synchronous motion transfer. Goodyear timing belts feature teeth that fit into corresponding grooves on pulleys, preventing slippage and ensuring efficient power transfer.
Key Features
- Eliminates lubrication and re-tensioning to reduce maintenance and labor
- Precisely formed and accurately spaced elastomeric teeth ensure correct engagement with pulley grooves
- Flexible neoprene backing with fiberglass tensile cord reinforcement
- Temperature range -22°F to +212°F (-30°C to +100°C)
- Cleaner, quieter, and lower-cost alternative to chain drives compared to chain drives
- Conforms to ISO 19347:2015 timing belt standards
Technical Specifications
- Pitch Length: 25 inches
- Pitch: 0.20 inches
- Belt Width: 0.37 inches
- Number of Teeth: 125
- Tooth Height: 0.05 inches
- Total Height: 0.09 inches
- Weight: 0.03 lbs
- Material: Flexible neoprene backing, fiberglass tensile cord reinforcement
- Temperature Range: -22°F to +212°F (-30°C to +100°C)
- Peripheral Speed: Up to 80 m/s
- Standard Compliance: ISO 19347:2015
Typical Applications
PowerGrip timing belts are suitable for office machines, machine tools, postage equipment, sewing machines, vending machines, agriculture, outdoor power equipment, food processing, HVAC, oil fields, wood, paper, sand, and gravel applications. Trapezoidal timing belts are commonly used in industrial machinery, printers, CNC machines, conveyor systems, and more.
Compatibility & Replacements
Compatible With
- XL-profile timing pulleys and sprockets
- 0.20″ pitch synchronous drive systems
- Industrial machinery with 0.37″ belt width requirements
- Light to moderate duty power transmission applications
- Temperature-controlled environments rated -22°F to +212°F
Replaces / Drop-In Replacement For
- Gates 250XL037 OEM equivalent
- Standard XL-profile 125-tooth timing belts with identical pitch length
- Applications previously using Goodyear 250XL037 OEM original equipment
Works With
- XL timing pulley systems (0.20″ pitch)
- Standard synchronous motor drives
- Power transmission systems requiring positive engagement
- Industrial machinery with timing belt configuration
