Overview
The ABB 3HAA3563-AJA/1 DSQC 236P is a proven servo axis control board designed for ABB robot controller systems. This circuit board handles motor commutation and power stage management for individual robot axes. The board integrates thermal dissipation and drive circuitry to ensure reliable, repeatable axis performance in high-cycle manufacturing and material handling applications.
Key Features
- Axis servo motor commutation and control
- Integrated heatsink for thermal management (GME 91005-141-D designation)
- Compatible with ABB DSQC 236P drive module architecture
- Proven reliability in existing ABB robotics installations
- Used, fully functional condition with cosmetic wear
Technical Specifications
- Board Type: Servo Axis Control / Motor Commutation
- Manufacturer: ABB (ASEA Brown Boveri)
- Part Number: 3HAA3563-AJA/1
- Module Designation: DSQC 236P
- GME Reference: 91005-141-D
- Form Factor: Single-width PCB with integrated heatsink
- Application: ABB robot axis drive control
- Condition: Used, fully operational
Typical Applications
- ABB S3 and S4 robot controller axis modules
- Industrial robot axis commutation and drive
- Precision motion control in manufacturing
- Material handling robot systems
- Multi-axis robotic automation platforms
Compatibility & Replacements
Compatible With
- ABB DSQC 236 series robot drive modules
- ABB S3 and S4 robot controller architectures
- ABB IRB series industrial robots
- Systems requiring individual axis servo control boards
Replaces / Drop-In Replacement For
- Original ABB 3HAA3563-AJA/1 units in existing systems
- Direct replacement for failed or degraded DSQC 236P axis boards
- Verify compatibility with your specific robot model and controller revision before ordering
Works With
- ABB Robotics Studio software
- ABB DSQC 236 drive module ecosystems
- ABB robotics system cabinets and harnesses
- Industrial Ethernet and fieldbus protocols where supported by host controller
