Overview
The GE Multilin 1240-0006-A2 VDN voltage divider network PCB is a critical component in GE Multilin SPM relay systems. This module connects exciter or field voltage to the SPM relay, enabling synchronization protection for industrial and commercial motor applications. The board slots into the relay assembly and requires minimal wiring for integration into existing electrical distribution systems.
Key Features
- Dedicated voltage divider network functionality for SPM relay systems
- Mounts via 4-screw bracket for secure, repeatable positioning
- Field-replaceable module design—swap complete unit in minutes without disturbing rear terminal wiring
- Compact circuit board layout engineered for industrial-grade reliability
- Exciter and field voltage connection support for motor synchronization applications
Technical Specifications
- Manufacturer: GE (General Electric)
- Part Number: 1240-0006-A2
- Product Type: Voltage Divider Network PCB
- Series: GE Multilin SPM Relay Systems
- Mounting: 4-screw bracket assembly
- Application: SPM relay synchronization protection
- Country of Origin: Japan
Typical Applications
The 1240-0006-A2 is used in:
- SPM (Synchronous Process Motor) relay-based protection systems
- Industrial motor control and synchronization circuits
- Electrical distribution panels requiring voltage monitoring and field control
- Legacy and modern GE Multilin relay installations
- Maintenance and replacement of failed voltage divider modules in draw-out relay cases
Compatibility & Replacements
Compatible With
- GE Multilin SPM relay systems and variants
- SR735-CASE draw-out relay configurations
- Industrial motor synchronization protection schemes
- Exciter and field voltage measurement circuits
Replaces / Drop-In Replacement For
- Original GE 1240-0006-A2 units in installed SPM relays
- Failed or aging voltage divider network modules in GE Multilin equipment
Works With
- GE Multilin SPM relay protection logic
- Standard industrial control wiring and terminal configurations
- Draw-out relay cases with rear terminal wiring compatibility
