Overview
The GE 7613-1 sealed beam lamp is an 8-watt, 6-volt PAR36 incandescent bulb engineered for emergency lighting, industrial equipment, and specialized lighting applications. This sealed beam design provides protection against environmental conditions and premature failure, making it ideal for outdoor and indoor industrial use. The C-6 filament delivers consistent light output with a 50-hour rated life.
Key Features
- PAR36 sealed beam construction resists weather and environmental degradation
- Slip-on terminal base enables quick, tool-free installation
- 400 MBCP (Mean Beam Candlepower) for focused, directional illumination
- 50-hour average rated life ensures extended service intervals
- Compact 4.5-inch diameter, 2.75-inch length for space-constrained fixtures
- Flood beam spread: 30° horizontal, 20° vertical coverage
Technical Specifications
- Wattage: 8W
- Voltage: 6V
- Lamp Type: PAR36 Sealed Beam Incandescent
- Base Type: Slip-On Terminals
- Filament: C-6
- Average Rated Life: 50 hours
- Center Beam Candlepower: 400 MBCP
- Maximum Overall Length: 2.75 inches
- Maximum Overall Diameter: 4.5 inches
- Beam Spread (Horizontal): 30°
- Beam Spread (Vertical): 20°
- Color Temperature: 3000K
- Lumens: 33
Typical Applications
- Building emergency lighting systems and exit signs
- Industrial equipment status indicators and work lights
- Outdoor spotlights and landscape lighting
- Portable work lamps and inspection fixtures
- Mining and heavy equipment task lighting
Compatibility & Replacements
Compatible With
- Any 6V emergency lighting fixture with PAR36 slip-on terminal socket
- Industrial machinery and control panel indicator systems
- Portable 6V work light assemblies
- Standard PAR36 reflector housing designs
Replaces / Drop-In Replacement For
- GE 45101
- GE 45102
- GE 7613 (earlier revision)
- Equivalent PAR36 6V sealed beam lamps with slip-on terminals
Works With
- 6V DC emergency lighting systems
- PAR36 sealed beam fixtures and reflectors
- Slip-on terminal connectors and wiring harnesses
- Industrial control panel wiring and circuits
