The Fujitsu DS1M Rectifier Diode 90 is a high-performance semiconductor device designed for efficient rectification in various electronic circuits.
Key Features
- High Voltage Rating: Capable of withstanding significant reverse voltages, ensuring reliable operation in high-voltage applications.
- High Current Capacity: Designed to handle substantial forward currents, making it suitable for power-intensive circuits.
- Fast Recovery Time: Exhibits rapid reverse recovery characteristics, minimizing switching losses and enhancing efficiency.
- Thermal Stability: Constructed to maintain performance across a wide range of operating temperatures, ensuring durability and longevity.
Applications
The DS1M Rectifier Diode 90 is ideal for use in:
- Power Supplies: Efficient conversion of AC to DC in various power supply units.
- Motor Drives: Reliable rectification in motor control circuits for industrial and consumer applications.
- Inverters: Effective performance in inverter circuits for renewable energy systems and uninterruptible power supplies.
- General Rectification: Suitable for a broad range of rectification needs in electronic devices and systems.
Technical Specifications
- Maximum Reverse Voltage (VRRM): 1000V
- Average Forward Current (IF(AV)): 1A
- Forward Voltage Drop (VF): 1.3V at 1A
- Reverse Recovery Time (trr): 250ns
- Operating Temperature Range: -55°C to 150°C
These specifications ensure that the DS1M Rectifier Diode 90 delivers consistent and reliable performance across various applications, making it a versatile component in electronic design.
