Overview
The Fluke 2200A-3020 CKT1 Rev H scanner assembly (part number 409607 Rev F) is a specialized circuit board component designed for integration with Fluke 2200 series temperature control systems. This assembly handles scanning operations and input signal conditioning for multi-channel temperature monitoring and control applications. As a legacy component, it is ideal for maintenance, repair, and replacement of existing Fluke 2200 installations.
Key Features
- CKT1 Rev H circuit card design optimized for Fluke 2200 platform
- 409607 Rev F assembly—factory-configured for scanner operation
- Supports multi-input scanning and signal routing
- Drop-in replacement for OEM Fluke 2200 series systems
- Fully tested and functional, ready for immediate deployment
Technical Specifications
| Manufacturer | Fluke Corporation |
| Part Number | 2200A-3020 |
| Assembly Designation | CKT1 Rev H / 409607 Rev F |
| Product Type | Scanner Assembly / Circuit Board |
| Application | Fluke 2200 Temperature Controller |
| Function | Input scanning and signal conditioning |
| Compatible Models | Fluke 2200 Series |
Typical Applications
- Replacement or repair of Fluke 2200 temperature control systems
- Industrial process monitoring and data acquisition
- Thermocouple and sensor input scanning for multi-point systems
- Legacy system maintenance and field upgrades
- OEM equipment repair and calibration support
Compatibility & Replacements
Compatible With
- Fluke 2200 Series Temperature Controller systems
- Fluke 2200 mainframe and cardcage assemblies
- Multi-input scanning applications
Replaces / Drop-In Replacement For
- Original Fluke 2200A-3020 scanner assemblies (all revisions)
- Legacy CKT1 circuit boards in Fluke 2200 systems
Works With
- Fluke 2200 controller firmware and software
- Standard thermocouple and RTD input signals
- Fluke calibration and measurement ecosystems
