Overview
The Fluke 409599 is an analog-to-digital (A/D) converter board designed for precision signal processing and data acquisition applications. This circuit board assembly, identified as model 2200A-3021 CKT1 Rev F and also referenced as 2200A-3005 CKT1 Rev M, represents proven Fluke engineering for reliable measurement and conversion functionality. The board is engineered to convert analog input signals into digital format with the accuracy and consistency expected from Fluke test and measurement equipment.
Key Features
- Analog-to-digital conversion for precision measurement applications
- Compatible with Fluke 2200A series test equipment and measurement systems
- Multiple circuit revision support (Rev F and Rev M variants)
- Compact printed circuit board form factor for integration into larger systems
- Established component design with proven field reliability
- Used/refurbished condition—fully functional and ready for deployment
Technical Specifications
- Part Number: 409599
- Model: 2200A-3021 CKT1 Rev F (also 2200A-3005 CKT1 Rev M)
- Component Type: Analog-to-Digital Converter Board
- Function: Signal conversion and measurement
- Form Factor: Printed circuit board assembly
- Application: Fluke test equipment and measurement systems
- Availability: Used/surplus, tested condition
Typical Applications
The Fluke 409599 A/D converter board is used in:
- Fluke 2200A series measurement instruments and test systems
- Laboratory and field test equipment requiring precision analog signal processing
- Equipment repair and refurbishment projects where original or compatible replacement boards are required
- Calibration and measurement systems requiring reliable A/D conversion performance
Compatibility & Replacements
Compatible With
- Fluke 2200A series test equipment
- Fluke measurement and test instruments incorporating A/D conversion modules
- Systems requiring precision analog-to-digital signal processing
Replaces / Drop-In Replacement For
- Fluke 2200A-3021 CKT1 earlier revisions
- Fluke 2200A-3005 CKT1 earlier revisions
- Verify specific revision compatibility (Rev F and Rev M noted) with your equipment documentation before ordering.
Works With
- Fluke 2200A series instruments
- Fluke service and repair operations
- Measurement and test systems using analog-to-digital conversion
- Verify compatibility with your system integrator or equipment documentation before ordering.
