Overview
The Esterline Angus S-22906-1 (also referenced as MS413B) is a chart recorder engineered for amp/volt measurement and data logging. This unit combines mechanical reliability with straightforward operation, making it a practical choice for industrial environments where continuous analog monitoring is required. The Esterline Angus S-22906-1 delivers time-stamped paper recordings of electrical parameters including current and voltage.
Key Features
- Amp/Volt recording capability for continuous electrical monitoring
- Paper chart drive mechanism for permanent data record
- Durable construction suitable for industrial environments
- Compatible with standard chart paper and pen systems
- Direct measurement without additional signal conditioning
Technical Specifications
- Manufacturer: Esterline Angus
- Model / Part Number: S-22906-1 (MS413B)
- Product Type: Chart Recorder
- Measurement Type: Amp/Volt
- Recording Method: Paper chart with pen drive
- Industry Application: Industrial data acquisition and monitoring
- Condition: Used, fully functional
Typical Applications
- Oil and gas operations — monitoring electrical loads and power consumption
- Manufacturing facilities — tracking equipment current draw and voltage stability
- Energy utilities — demand and power survey recording
- Maintenance departments — equipment diagnostics and trend analysis
- Test and measurement labs — baseline electrical parameter documentation
Compatibility & Replacements
Compatible With
- Standard Esterline Angus chart paper (37020-X and equivalent)
- Esterline Angus recorder pen systems
- DC and AC electrical measurement circuits
- Industrial electrical monitoring applications
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The S-22906-1 shares electrical measurement capabilities with other Esterline Angus Miniservo III series recorders; consult manufacturer documentation for exact interchangeability.
Works With
- Esterline Angus chart paper rolls and paper feed mechanisms
- Standard pen and stylus accessories compatible with Esterline Angus recorders
- Manual configuration for DC/AC voltage and current ranges
