Overview
The Elesa 265211-C2 is a guard wing handle (EWP.110-EH-C2 series) engineered for machine guard and automation system applications. This handle is specifically designed for single-leaf door installations, providing ergonomic access while maintaining operator safety through rugged technopolymer construction.
Key Features
- Technopolymer (PBT-based) construction with colored cap for visibility and customization
- Hexagon socket mounting holes accommodate cylindrical-head screws and hexagon-head screws
- Closed design optimized for single-leaf door installations
- Ergonomic profile reduces operator fatigue during repeated access
- Low-profile ledge mounting compatible with standard industrial door frames
- Corrosion-resistant finish suitable for washdown and humid environments
Technical Specifications
The EWP.110-EH-C2 wing handle series meets standard machine guard requirements with the following characteristics:
- Maximum tightening torque for screw assembly: 3 Nm
- Mount type: Ledge handle (pass-through holes)
- Socket type: Hexagon socket for M5 or M6 fasteners
- Material: Polyester-based technopolymer (PBT)
- Finish: Colored cap with glossy finish (Elecolors range)
- Design standard: Single-leaf door optimization
Typical Applications
- Machine access guards and safety enclosures
- Control cabinet and electrical panel doors
- Automated production system guard doors
- Machinery protective barriers requiring frequent operator access
- Washdown and hygiene-critical environments
Compatibility & Replacements
Compatible With
- Standard industrial machine guard frame systems
- Single-leaf swing door enclosures
- M5 and M6 hexagon socket fastener installations
- Automation system access requirements per ISO 14119 safety standards
Replaces / Drop-In Replacement For
Verify compatibility with your specific machine guard or enclosure system before ordering. The 265211-C2 is the specified Elesa model for EWP.110-EH-C2 applications; related ESP series models (265111-C2) are designed for double-leaf doors and are not direct replacements.
Works With
- Elesa Elecolors customization color palette
- Standard M5/M6 hex socket fastener specifications
- ISO 14119 industrial safety door interlock systems
- Class-A machine guard installation requirements
