Overview
The Eaton Dynamatic 15-796-01 circuit board (model 70-243-1, Rev A) is a critical component in Eaton Cutler-Hammer’s Dynamatic line of motor control and industrial automation equipment. This printed circuit board integrates power management, signal conditioning, and drive logic functionality essential to modern industrial motion control systems.
Key Features
- Genuine Eaton Dynamatic component for OEM compatibility
- Revision A design — established performance history in installed base
- Dual part number configuration (15-796-01 / 70-243-1) ensures proper identification and replacement
- Precision PCB construction for reliable signal processing and power switching
- Used unit, tested and functional — reduces downtime on motor control repairs
Technical Specifications
- Manufacturer: Eaton Cutler-Hammer
- Part Number: 15-796-01 / 70-243-1
- Revision: A
- Product Category: Printed Circuit Board (PCB)
- Application: Motor drive control, automation equipment
- Condition: Used, tested, fully functional
Typical Applications
The Eaton Dynamatic 15-796-01 circuit board is deployed in:
- DC and AC motor speed control systems
- Industrial automation equipment and process control
- Dynamatic variable frequency drives (VFDs) and soft starters
- OEM equipment rebuild and field service replacement
- Motion control systems requiring precision signal processing
Compatibility & Replacements
Compatible With
- Eaton Dynamatic motor control systems
- Eaton Cutler-Hammer industrial automation equipment
- Original equipment manufacturer (OEM) Dynamatic-based installations
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or controls engineer before ordering. The dual part number format (15-796-01 and 70-243-1) indicates this unit is a direct replacement only for equipment originally specified with these model numbers.
Works With
This PCB integrates into Eaton Dynamatic equipment utilizing standard industrial control protocols including analog and digital I/O, fieldbus communication where applicable, and classic DC/AC power switching architecture. Compatibility with modern communication protocols (EtherNet/IP, PROFINET, Modbus) depends on the host equipment integration and is not inherent to the board itself.
