Overview
The Eaton Durant 53301404 totalizer ratemeter counter is a compact, battery-powered electronic counter designed for precise measurement and monitoring of process flow and counting applications. Built with an extended temperature operating range, this unit provides reliable performance in harsh industrial environments where standard counters may fail. The Eaton Durant 53301404 features a clear LCD display for easy reading and integrates seamlessly into PLC-based automation systems.
Key Features
- 1/TAU ratemeter with totalizer functionality for dual monitoring capability
- Battery-powered operation with internal 3V lithium cell—no external power required
- Extended operating temperature range (–20 to +70 °C / –4 to 158 °F) for cold storage and high-heat applications
- LCD display for clear, easy-to-read output in all lighting conditions
- Compact, industrial-grade enclosure designed for panel or field mounting
- Five-year battery life expectancy with replaceable battery module
Technical Specifications
- Model Number: 53301404
- Product Type: Electronic Totalizer/Ratemeter Counter
- Power Source: Internal 3V lithium battery (non-replaceable in some configurations)
- Battery Life: 5+ years typical
- Display Type: LCD digital display
- Response Mode: 1/TAU ratemeter with totalizer integration
- Operating Temperature: –20 to +70 °C (–4 to 158 °F)
- Storage Temperature: –20 to +70 °C (–4 to 158 °F)
- Operating Humidity: 60% noncondensing
- Weight: 62 g (2.2 oz)
- Reverse Polarity Protection: Yes (when powered from external 10–30 Vdc backlight option)
- Series: Durant Electronic Counters
- Manufacturer: Eaton Cutler-Hammer
Typical Applications
- Flow rate monitoring and totalization in fluid systems
- Production line count tracking and batch control
- Process monitoring in food, beverage, and pharmaceutical manufacturing
- Cold storage and cryogenic environment process monitoring
- PLC-integrated pulse counting for speed and distance measurement
- Preset counter and alarm triggering in automated assembly
Compatibility & Replacements
Compatible With
- Eaton/Cutler-Hammer PLC and automation control systems
- Low-voltage DC and contact input pulse sources
- Industrial sensor and encoder outputs (NPN/PNP compatible configurations available)
- DIN-rail and panel-mount automation architectures
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering. Similar legacy models in the Durant product line include 53300404 and 53301405, but confirm exact feature and mounting compatibility with the 53301404 before substitution.
Works With
- Eaton SCADA and supervisory control systems
- Industrial automation controllers requiring discrete process counting
- Rockwell Automation PLC frameworks with input module integration
- Standard pulse and TTL logic inputs from sensors and encoders
