Druckring #L 110 (2) 60HUB Retaining Ring 313911

Druckring #L 110 (2) 60HUB Retaining Ring 313911

The Druckring #L 110 (2) 60HUB Retaining Ring 313911 is a high-quality internal retaining ring designed for secure component retention in various industrial applications. This two-turn Spirolox retaining ring is engineered to fit a housing diameter of 110.00 mm, ensuring a precise and reliable fit.

Key Features

• Design: Two-turn internal Spirolox retaining ring
• Housing Diameter: 110.00 mm
• Material Options: Available in Carbon Steel SAE 1070-1090, 302 Stainless Steel, and 316 Stainless Steel
• Crimp: Yes
• Ring Shear: 155,000 N (with a safety factor of 3)
• Groove Yield: 88,510 N (assuming groove material yield strength of 45,000 psi and a safety factor of 2)

Applications

This retaining ring is ideal for applications requiring secure axial positioning of components within a housing, such as in pumps, gearboxes, and other machinery where precise component alignment is critical.

Material Selection

Choosing the appropriate material is essential for optimal performance:

• Carbon Steel SAE 1070-1090: Offers high strength and durability for general applications.
• 302 Stainless Steel: Provides excellent corrosion resistance and good mechanical properties.
• 316 Stainless Steel: Delivers superior corrosion resistance, especially in marine or chemically aggressive environments.

Ensure compatibility with your specific application requirements when selecting the material.

Installation and Maintenance

Proper installation is crucial for the retaining ring’s performance. Ensure the groove dimensions match the ring specifications, and follow standard installation procedures to maintain the integrity and functionality of the assembly.

Regular inspection and maintenance are recommended to ensure the retaining ring continues to perform effectively over time.
