Overview
The Dayton 6EAW5 reversing IEC magnetic contactor is an electrically operated switching device designed for reversible motor control applications. With a 120V AC coil and 9A full-load inductive rating, this three-pole contactor delivers the switching performance required in industrial automation, HVAC systems, and variable-speed motor control circuits. The IEC-standard design ensures compatibility with modern control architectures while maintaining proven reliability across industrial and commercial installations.
Key Features
- Reversing capability: Enables forward/reverse motor control in a single compact unit
- Three poles: Provides switching for three-phase power circuits and motor leads
- 120V AC coil: Standard control voltage for integration with existing automation systems
- 1NO auxiliary contact: Enables status feedback and interlocking logic
- IEC standard design: Compact footprint meets international electrical standards
- 50/60 Hz operation: Supports both US and international power frequencies
Technical Specifications
Typical Applications
The Dayton 6EAW5 is well-suited for applications including conveyor drive reversing, reversible pump motors, hoist and crane controls, fan reversing circuits, and bidirectional motor starters in manufacturing and process automation. Its compact IEC form factor makes it ideal for distributed control panels and compact enclosures where space is limited.
Compatibility & Replacements
Compatible With
- Three-phase AC motor circuits (208V, 240V, 480V, 575V motor loads)
- Single-phase motor circuits (120V, 240V)
- Standard industrial control systems and motor starter assemblies
- PLC-based and relay logic control platforms
- IEC-standard control panel enclosures
Replaces / Drop-In Replacement For
Verify specific interchangeability with your equipment documentation or system integrator. The Dayton 6EAW5 shares the same 120V AC coil voltage and 9A inductive rating as other reversing contactors in the Dayton 6EA series with equivalent specifications.
Works With
- Electromechanical motor starters and overload relay combinations
- Allen-Bradley, Siemens, Schneider Electric, and other industrial control platforms
- EtherNet/IP and PROFINET-enabled remote I/O via external gateways
- Standard hardwired interlock circuits and pushbutton station controls
- Both 50 Hz and 60 Hz power distribution systems
