Overview
Cutler-Hammer SV9050AP-5M0A01 is a SV9000 series variable frequency drive (VFD) engineered for industrial motion control and automation applications. This 65A/50HP AC drive features a standard protected chassis (IP20) enclosure, making it suitable for panel mounting in manufacturing, pump control, compressor drive, and material handling systems. The compact design delivers reliable performance with consistent voltage regulation across a 440–500V three-phase input range.
Key Features
- 50 horsepower motor load rating with 65A continuous current capacity
- Three-phase AC input, 440–500V voltage range for flexible installation
- Standard protected chassis (IP20) enclosure for indoor industrial environments
- SVMulti-line alphanumeric control panel for straightforward parameter configuration
- Constant-torque drive rating; suitable for fans, pumps, and conveyors
- Modular design supports field upgrades and repairs
Technical Specifications
- Output Rating: 50 HP
- Output Current: 65 A continuous
- Input Voltage: 440–500V, three-phase
- Series: SV9000
- Enclosure Type: Standard Protected Chassis (IP20)
- Control Interface: SVMulti-line Alphanumeric
- Drive Rating: Constant Torque
- Dynamic Braking: No integrated chopper circuit
- Mounting: Panel/DIN rail compatible
- Condition: Remanufactured
Typical Applications
The SV9050AP-5M0A01 is widely deployed in:
- Centrifugal pump and compressor drives — constant-torque applications requiring smooth motor control and soft-start capability
- Conveyor and material handling systems — reliable frequency and speed adjustment for production lines
- Fan and blower speed regulation — energy-efficient motor control with reduced inrush current
- Machine tool spindle drives — precision speed control in industrial machining environments
- OEM panel integration — compact form factor fits standard electrical enclosures in manufacturing equipment
Compatibility & Replacements
Compatible With
- Three-phase AC induction motors, 50 HP maximum continuous load
- Standard industrial control circuits and hardwired start/stop logic
- Programmable Logic Controllers (PLCs) via discrete I/O or optional communication modules
- Panel-mount installations with 440–500V three-phase supply
- NEMA Type 1 and Type 12 electrical enclosures
Replaces / Drop-In Replacement For
- SV9050AP-5M0A00 (earlier variant of the same series)
- Cutler-Hammer SV9000 series drives with identical 50HP/65A specifications
- Verify compatibility with your system integrator before ordering to confirm software and communication configurations.
Works With
- Communications: Discrete hardwired I/O; optional fieldbus modules for EtherNet/IP or MODBUS integration
- Control Software: SVMulti parameter interface for programming ramp times, frequency limits, and overload thresholds
- Power Distribution: Standard three-phase motor starters, soft-starter bypass circuits, and soft-start ramp control
- Motor Compatibility: Any NEMA Design B or C three-phase squirrel-cage induction motor rated for 50 HP or less
