The Cognex DM302L 825-0340-1R A Industrial Barcode Reader is a high-performance, fixed-mount scanner engineered for precise and rapid decoding of both 1D and 2D barcodes in demanding industrial settings.
Key Features
- Advanced Imaging Capabilities: Equipped with a 1/1.8″ CMOS sensor, the DM302L delivers a high-resolution image of 1280 x 1024 pixels, ensuring accurate capture of intricate barcode details.
- Liquid Lens Autofocus: The integrated liquid lens technology provides dynamic autofocus, allowing the scanner to adapt swiftly to varying working distances without mechanical adjustments.
- High-Speed Performance: With a frame rate of up to 60 frames per second, the DM302L is adept at handling high-speed production lines, maintaining efficiency without compromising accuracy.
- Versatile Code Reading: Supports a wide array of 1D barcodes, including Codabar, Code 39, Code 128, and GS1 DataBar, making it suitable for diverse industrial applications.
- Robust Connectivity: Offers Ethernet and RS-232 communication interfaces, facilitating seamless integration into existing industrial networks and control systems.
- Industrial Durability: Designed to withstand harsh environments, the scanner operates on a 24V DC power supply with a maximum power consumption of 20W, ensuring reliable performance in continuous industrial operations.
Technical Specifications
- Sensor Type: 1/1.8″ CMOS
- Lens Type: Liquid Lens (Autofocus)
- Image Resolution: 1280 x 1024 pixels
- Frame Rate: Up to 60 FPS
- Supported 1D Symbologies: Codabar, Code 39, Code 128, Code 93, Interleaved 2 of 5, MSI, GS1 DataBar, Postal, UPC/EAN/JAN
- Communication Interfaces: Ethernet, RS-232
- Power Supply: 24 VDC, 20 W Max
- Environmental Rating: IP65/IP67
- Weight: 1.4 lbs
The Cognex DM302L 825-0340-1R A is an ideal solution for manufacturers seeking a compact, intelligent scanning device capable of dynamic focus adjustment and high-speed barcode reading in challenging industrial environments.
