Overview
The CKD L3000 is an industrial-grade pneumatic lubricator engineered to provide controlled oil misting in compressed air systems. With a rated pressure of 1.0MPa, this modular lubricator integrates easily into filter-regulator-lubricator (FRL) assemblies and standalone pneumatic circuits. The double-wall plastic bowl design enables 360° visibility for monitoring oil levels and drip patterns from any angle.
Key Features
- Modular design for flexible system integration and FRL combination compatibility
- Oil drop adjustment knob with removal prevention for consistent dosing
- Double-wall polycarbonate bowl for 360° oil dripping visibility
- Integrated one-touch connection and disconnection ports
- O-ring drop prevention ensures cleaner pneumatic systems
- Compact, lightweight construction—50% lighter than conventional designs
Technical Specifications
| Pressure Rating | 1.0MPa (10 bar) |
| Product Type | Pneumatic Lubricator |
| Series | L3000-W (White Series) |
| Bowl Material | Polycarbonate |
| Oil Storage Capacity | 85 cc |
| Port Connection Type | One-touch connection / NPT / RC thread options |
| Port Size (Standard) | 3/8″ (10 mm) inlet; 1/4″ also available |
| Common Models | L3000-10-W (3/8″ NPT), L3000-8N-W-C (1/4″ NPT), L3000-10N-W (3/8″ NPT no drain) |
| Manufacturing Standard | ISO general industrial pneumatic component |
| Condition | Used, Fully Functional |
Typical Applications
- Pneumatic tool lubrication systems (impact wrenches, grinders, drills)
- Industrial automation FRL assemblies in manufacturing plants
- Compressed air distribution networks requiring mist lubrication
- Modular pneumatic control circuits in automotive and assembly facilities
- General industrial machine air line conditioning
Compatibility & Replacements
Compatible With
- CKD FRL combination units (L3000-W series integrates into modular F, R, L stacks)
- Standard ISO pneumatic connectors and adapters
- Rc (ISO metric) and NPT (US) thread port configurations
- CKD piping adapter sets and mounting brackets
- Pneumatic systems operating between 0.07–1.0 MPa
Replaces / Drop-In Replacement For
- Earlier CKD L3000 variants (L3000-10, L3000-8N configurations)
- Other modular pneumatic lubricators in the same pressure range
- Verify exact model compatibility with your system integrator before ordering
Works With
- ISO 4401 (Cetop) mounting standards
- Standard mineral and synthetic pneumatic oils
- CKD F (filter) and R (regulator) series components
- One-touch quick-disconnect couplings (standard and threaded adapters)
- Automated and manual drain valve options
