Overview
The Carlo Gavazzi IA08BSF20PO inductive proximity sensor combines robust detection capability with industrial-grade reliability. This M8-housed sensor detects both ferrous and non-ferrous metallic targets, making it suitable for general-purpose automation applications including position sensing, part counting, and safety interlocking. The solid-state switching output eliminates mechanical wear and extends operational life in demanding factory environments.
Key Features
- M8 cylindrical stainless steel housing for compact mounting
- PNP transistor output with NO (normally open) switching logic
- Detects ferrous and non-ferrous metallic targets
- IP67 sealed housing for washdown and outdoor installations
- Wide supply voltage range (10–36 VDC) for flexible system integration
- Max switching frequency up to 2 kHz for rapid response applications
Technical Specifications
- Housing Material: Stainless steel
- Housing Size: M8
- Detection Type: Inductive
- Output Type: PNP transistor
- Output Logic: NO (normally open)
- Supply Voltage: 10–36 VDC
- Max Output Current: 200 mA
- Max Switching Frequency: 2 kHz
- Operating Temperature Range: −25°C to +70°C
- IP Rating: IP67
- Connection Type: M12 plug connector
Typical Applications
- Parts detection and counting on conveyor lines
- Position sensing in machine tools and transfer equipment
- Safety gate and access door interlocks
- Level and proximity detection in packaging machinery
- Mobile equipment proximity warning systems
- Food, beverage, and pharmaceutical production lines
Compatibility & Replacements
Compatible With
- 24 VDC industrial PLC and controller input modules
- Any 10–36 VDC control system with PNP input acceptance
- Standard industrial automation wiring harnesses and connectors
- M12 A-coded socket connections (standard industrial connector)
- Discrete I/O cards and logic controllers (24 VDC preferred)
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering. Similar M8 PNP sensors from competing manufacturers may require connector or output verification.
Works With
- Rockwell Automation CompactLogix and ControlLogix input modules
- Siemens S7-1200 and S7-1500 series with digital input cards
- Mitsubishi FX, Q, and A series PLCs
- Omron CP series programmable controllers
- Standard PLC discrete input circuits (24 VDC logic)
- Relay and contactor control circuits
