Buss Cooper Bussmann 3A Fuse BAF-3

Bussmann BAF-3 Fast-Acting Midget Fuse

The Bussmann BAF-3 is a 3-amp, 250-volt fast-acting midget fuse designed to provide reliable overcurrent protection in various electrical applications. Its compact size and efficient performance make it suitable for safeguarding general-purpose circuits, lighting systems, and meter circuits.

Key Features

• Fast-Acting Response: Quickly interrupts overcurrent conditions to protect sensitive equipment.
• Compact Dimensions: Measures 13/32 inches in diameter and 1-1/2 inches in length, facilitating easy integration into tight spaces.
• Durable Construction: Features a fiber tube body with nickel-plated brass end caps for enhanced conductivity and corrosion resistance.
• High Interrupting Capacity: Rated at 100 amperes at 250 VAC and 10,000 amperes at 125 VAC, ensuring robust protection against short circuits.
• Color-Coded Identification: Green color coding indicates a maximum voltage rating of 250 VAC, aiding in quick identification.

Specifications

• Current Rating: 3 amperes
• Voltage Rating: 250 VAC
• Interrupting Rating: 100 A at 250 VAC; 10,000 A at 125 VAC
• Body Material: Fiber tube
• End Caps: Nickel-plated brass
• Dimensions: 13/32 in. diameter x 1-1/2 in. length
• Approvals: CE, UL 248-14, CSA

Applications

The BAF-3 fuse is ideal for use in:

• General-purpose electrical circuits
• Lighting circuit protection
• Meter circuits

Its fast-acting nature ensures prompt response to overcurrent situations, thereby protecting equipment and maintaining system integrity.

Installation and Compatibility

Designed for easy installation, the BAF-3 fuse fits standard midget fuse holders and is compatible with various fuse block series, including BM, BMM, C2617, C5268, CHM, HEB, HEX, HPG, and HPS. Its non-rejection design allows for straightforward replacement without the need for specialized holders.

For enhanced protection and to minimize potential arc flash hazards, consider upgrading to the LP-CC series, which offers additional safety features and reduces the risk of misapplication.

Ensure that the BAF-3 fuse is installed in accordance with the manufacturer’s guidelines and local electrical codes to achieve optimal performance and safety.
