Overview
The Bussmann H60060-3CR fuse holder is a 3-pole Class H rated power distribution block designed for 600V circuit protection applications up to 60A. Built with thermoplastic housing and bright tin-plated bronze clips, this Bussmann H60060-3CR delivers reliable performance in industrial control panels and power distribution cabinets. The box lug terminal design with reinforced spring connections ensures secure wire contact and safe fuse installation.
Key Features
- 3-pole configuration for three-phase power distribution
- 600V AC/DC voltage rating with 31–60A current range
- Thermoplastic construction with tin-plated bronze clips for durability
- Box lug terminals with reinforced spring clip design
- 10 kAIC interrupt current rating for short-circuit protection
- Accepts Class H and K5 fuses
- UL listed and CSA certified
Technical Specifications
- Voltage Rating: 600V AC / 600V DC
- Current Rating: 31–60A
- Fuse Class: Class H & K5
- Poles: 3
- Terminal Type: Box Lug with Spring Clip
- Wire Size: 14–2 AWG copper / 8–2 AWG aluminum
- Interrupt Rating: 10 kAIC
- Dimensions: 7.36″ L × 4.94″ W × 2.06″ D
- Material: Thermoplastic with tin-plated bronze contacts
- Certifications: UL listed, CSA certified
- Mounting: DIN rail or bolt-down
Typical Applications
The H60060-3CR is ideal for three-phase motor protection, power distribution panels, industrial control cabinets, and machinery branch circuits. It is commonly used in:
- Manufacturing and processing equipment
- HVAC and refrigeration systems
- Industrial panel boards
- Machine tool protection circuits
- Commercial power distribution systems
Compatibility & Replacements
Compatible With
- Class H fuses (KTS series, FRS series)
- Class K5 fuses
- Bussmann/Eaton fuse accessories and enclosures
- Standard DIN rail mounting systems
- Industrial control panel wiring (14–2 AWG copper, 8–2 AWG aluminum)
Replaces / Drop-In Replacement For
The H60060-3CR is a direct replacement for earlier Bussmann H600 series 3-pole fuse blocks rated 600V, 31–60A. Similar Class H blocks from the same manufacturer lineup share pin configurations and mounting footprints. Verify compatibility with your system integrator before ordering if retrofitting older equipment.
Works With
- Bussmann Class H and K5 fuses
- Industrial control systems and motor starters
- Power distribution automation platforms
- Standard three-phase 480V and 600V power systems
- Building management and HVAC controllers
