Overview
The BradPower Motor Cordset 103000A45M070 is a pre-molded industrial cordset engineered for reliable power distribution in manufacturing, packaging, and assembly equipment. This 3-pole configuration replaces traditional hard-wired motor connections with a modular, quick-connect system that reduces installation complexity and improves system flexibility.
Key Features
- 3-pole (MC) to female pigtail (FP) connector configuration
- 7-meter (23-foot) length with 18/3 AWG conductors
- PVC cable jacket for standard industrial environments
- Crush-resistant, factory-molded connectors
- Modular quick-connect system eliminates conduit and raceway installation
- Supports single and 3-phase motor applications
Technical Specifications
- Connector Type: BradPower (MC) Male to Female Pigtail
- Pole Configuration: 3 poles
- Conductor Size: 18 AWG
- Cable Length: 7 meters (23 feet)
- Cable Material: PVC
- Standard Voltage Rating: 600V
- Connector Size: A-Series (7/8″ – M22)
Typical Applications
- General-purpose AC motor power distribution
- Packaging machinery and conveyor systems
- Production line motor connections
- OEM equipment integration
- Quick-changeover production systems requiring modular connectivity
Compatibility & Replacements
Compatible With
- BradPower receptacles and connector panels (A-Series M22)
- Single-phase and 3-phase motor circuits rated up to 600V
- Standard industrial control systems and motor starters
- Equipment designed for modular power distribution
Replaces / Drop-In Replacement For
- Direct replacement for existing BradPower 103000A45M070 cordsets in motor applications
- Alternative to hard-wired conduit connections in machinery upgrade projects
Works With
- BradPower A-Size (M22) connector ecosystem
- Industrial motor control circuits and VFD systems
- Both new installations and retrofit applications
- Standard three-phase distribution panels
