Overview
The Bodine 23T3BEHY 2420SW4038 is a single-phase, 115V AC synchronous gearmotor from the HY-Sync family. Designed for precision timing and low-speed synchronous drive applications, this unit delivers consistent RPM locked to line frequency with Class F insulation. The reversible design enables bidirectional operation, making it ideal for applications requiring forward/reverse control without additional contactors. Manufactured in the United States, this motor/gearmotor combines reliable synchronous performance with compact parallel-shaft gearbox integration.
Key Features
- 115V single-phase AC operation, 50/60 Hz compatible
- Reversible motor for forward and reverse operation
- Synchronous design — RPM locked to line frequency for precision timing
- Parallel shaft gearbox configuration for compact installation
- Class F insulation for thermal reliability
- Domestic USA manufacture and assembly
Technical Specifications
Verify all specifications against the product nameplate before installation.
- Input Voltage: 115V AC, single-phase
- Frequency: 50/60 Hz
- Full Load Amps: 0.15 A
- Base Motor Speed: 60 RPM (nominal at 60 Hz)
- Insulation Class: F
- Gearbox Type: Parallel shaft
- Reversible: Yes
- Manufacturer: Bodine Electric Company
Typical Applications
- Timing-critical conveyor and material handling systems
- Precision packaging and labeling equipment
- HVAC damper actuators and louver drives
- Carousel and rotary indexing mechanisms
- Display case turntables and merchandising drives
- Sign and display rotation systems
Compatibility & Replacements
Compatible With
- Standard 115V single-phase AC control circuits (50/60 Hz)
- Reversing contactors and manual forward/reverse switches
- Mechanical duty-cycle timers and programmable relay controls
- Line-voltage HVAC control systems
Replaces / Drop-In Replacement For
The Bodine 23T3BEHY 2420SW4038 is a specific model variant within Bodine’s HY-Sync synchronous motor family. Verify compatibility with your system integrator before ordering for confirmed cross-reference applications.
Works With
- Reversing and single-phase AC motor starters
- Mechanical and electrical duty-cycle timers
- Standard 115V AC electrical panels and branch circuits
- Capacitor-start or capacitor-run auxiliary controls (where applicable)
