Overview
The Baumer BHF 16.05A2000/10600158 is a robust incremental encoder designed for accurate motion control and feedback applications. This hollow shaft incremental encoder leverages optical sensing technology to deliver reliable position and speed measurement in industrial automation systems. With its proven field performance and straightforward integration, the BHF 16.05A2000 serves as a drop-in upgrade or replacement for existing encoder installations.
Key Features
- Optical sensing principle — enables high resolution and accuracy with minimal drift
- Hollow shaft design — 12mm bore diameter accommodates direct coupling to motor or shaft
- 5V TTL output (05A designation) — directly compatible with industrial controller inputs and edge-detection logic
- Wide supply voltage range — operates from 5 to 30 VDC, adapting to 24V and single-supply systems
- IP42/IP65 protection classes — suitable for clean factory and moderately harsh environments
- Temperature rated — operates across -20°C to +85°C ambient range for consistent performance
Technical Specifications
- Operating speed: Up to 12,000 rpm (IP42) / 6,000 rpm (IP65)
- Voltage supply: 5–30 VDC
- Output type: TTL-compatible push-pull (05A = 5V antivalent)
- Switching frequency: Up to 750 kHz
- Shaft type: Hollow, 12 mm diameter
- Housing: Aluminum
- Operating temperature: -20°C to +85°C
- Sensing method: Optical
- Weight: Approximately 300 g
- Protection class: IP42 or IP65 (verify with system integrator)
Typical Applications
- Motor speed feedback and closed-loop position control in CNC machines and industrial robots
- Conveyor belt speed monitoring and synchronization on production lines
- Servo motor feedback in automated assembly and material handling systems
- Spindle speed measurement and regulation in precision machining centers
- Angular velocity monitoring in printing, textile, and packaging equipment
Compatibility & Replacements
Compatible With
- PLC analog input modules and high-speed counter cards (TTL pulse input)
- Industrial controllers with optical isolation or differential input stages
- Motion control software supporting quadrature and single-channel pulse inputs
- 24 VDC control systems via external 5V supply or optional level shifter
- Standard DIN rail-mounted automation cabinets
Replaces / Drop-In Replacement For
- Baumer BHF 16.05A2000-L2-5 (standard L-mount variant)
- Similar 12 mm hollow shaft optical encoders from competing suppliers (verify mounting and electrical interface)
- Verify compatibility with your system integrator before ordering to confirm mounting and cable requirements
Works With
- Allen-Bradley ControlLogix and CompactLogix high-speed input modules
- Siemens S7-1200, S7-1500, and TIA Portal automation platforms
- Mitsubishi FX and Q-series PLC counter inputs
- Omron CP/CJ-series and Sysmac controllers with pulse input capability
- Schneider Electric M241/M251 with quadrature input modules
- Standard industrial quadrature and TTL-level motion control interfaces
