Overview
The Barber Colman A12036 0280 Temperature Controller 560 is a legacy analog/digital temperature controller engineered for precision climate control in HVAC, refrigeration, and process control applications. Part of the 560 Series, this controller epitomizes precision and reliability in temperature management, offering a comprehensive suite of features suitable for diverse industrial applications. The unit operates on proportional, integral, and derivative (PID) control algorithms to maintain setpoint stability across varying load conditions.
Key Features
- Proportional, reset, and rate control with auto-manual output modes
- Electric actuator positioning with slidewire proportioning feedback
- Internal temperature setpoint configuration
- Rear terminal wiring for standard industrial installation
- Compact design suitable for panel and standalone mounting
- Advanced control algorithms and temperature sensing technology ensure meticulous temperature regulation with exceptional stability and repeatability
Technical Specifications
| Model Number | A12036 0280 / 560 |
| Manufacturer | Barber Colman |
| Input Voltage (50 Hz) | 110–220 V AC |
| Input Voltage (60 Hz) | 120–240 V AC |
| Control Type | Proportional, Integral, Derivative (PID) |
| Output Configuration | Electric Actuator Positioning / Slidewire |
| Setpoint Type | Internal Temperature Reference |
| Product Category | Temperature Controller / Thermostat |
| Industry Classification | HVAC & Refrigeration Controls |
| Status | Used Surplus |
Typical Applications
- Commercial HVAC systems and climate control
- Refrigeration and cold storage temperature management
- Process heating and cooling loops
- Industrial process control requiring precise setpoint maintenance
- Legacy system retrofit and replacement
- Backup or redundant temperature control systems
Compatibility & Replacements
Compatible With
- Standard industrial panel cutout installations (6 × 6 inch opening)
- Thermocouple and RTD sensor inputs
- Manual-to-automatic switching systems
- Electric valve and damper actuator control circuits
- Proportional feedback systems with slidewire positioning
Replaces / Drop-In Replacement For
- The Barber-Colman MODEL 3504 CONTROLLER easily replaces the 560
- Earlier Barber Colman 560 and 570 controllers (legacy models)
- Verify compatibility with your system integrator before ordering, as panel cutout dimensions and wiring configuration may differ slightly between enclosure types
Works With
- Traditional terminal strip wiring (rear-mounted connections)
- Proportional output positioning feedback systems
- Motorized valve and damper actuators
- Manual-override capability for emergency operation
- Field-adjustable proportional band and reset rate tuning
