Overview
The Banner QS18VP6LP is a QS18 series all-purpose photoelectric sensor designed for retro-reflective (polarized) sensing applications. The Banner QS18VP6LP-77853 variant comes pre-configured with standardized specifications and is widely used in automated manufacturing, packaging, and material handling systems. It combines proven WORLD-BEAM optics with a compact 18 mm threaded M18 barrel housing, making it a drop-in replacement for hundreds of legacy sensor styles.
Key Features
- Polarized retro-reflective sensing mode with 3.5 m (11.5 ft) operating range
- Complementary PNP output with selectable Light-ON or Dark-ON operation via potentiometer
- Universal 18 mm threaded M18 barrel mount for quick installation
- 2 m (6.5 ft) pre-wired cable with bare-end flying leads for flexible integration
- Visible red LED indicator (650 nm) for easy alignment and troubleshooting
- IP67 / NEMA 6 sealed housing rated for -20 to +70°C ambient temperature
Technical Specifications
- Supply Voltage: 10–30 VDC (nominal 12 or 24 VDC)
- Output Type: Complementary PNP transistor
- Sensing Range: 3.5 m in polarized retro-reflective mode
- Sensing Beam: Visible red LED (650 nm)
- Cable Length: 2 m (6.5 ft) with bare-end leads
- Mount Style: M18 threaded barrel
- Housing Material: Thermoplastic with acrylic lens
- IP Rating: IP67 / NEMA 6 (fully sealed)
- Operating Temperature: −20 to +70°C
- Part Number: QS18VP6LP (internal Banner part 61630)
Typical Applications
The Banner QS18VP6LP excels in high-speed production environments where retro-reflective sensing is preferred:
- Bottling, canning, and beverage line detection
- Packaging and carton presence/absence verification
- Conveyor sorting and diverter control
- Assembly line part counting and positioning
- Material handling and pallet detection
- Edge and label detection on printed materials
Compatibility & Replacements
Compatible With
- Allen-Bradley / Rockwell Automation CompactLogix and ControlLogix controllers with 24 VDC I/O modules
- Siemens S7-1200, S7-1500, and SIMATIC ET 200 I/O systems
- Mitsubishi FX3U, Q-series, and L-series PLCs with 24 VDC inputs
- Omron CP1E, CP2E, and NJ-series controllers
- Schneider Electric Modicon M241, M251 with TM3 analog/digital modules
- EtherNet/IP, PROFINET, and DeviceNet networks via appropriate gateway / scanner modules
- Any standard 10–30 VDC DC power supply with PNP input capability
