<h2>Overview</h2>
<p>The <strong>Banner Q25AW3LPQ1</strong> is a self-contained retroreflective photoelectric sensor from Banner’s Q25 series. Designed for industrial automation, this polarized retroreflective sensor uses infrared light and a reflector to detect objects at extended ranges without requiring separate emitters and receivers. It excels in fixed-field sensing applications where reliability and ease of installation are critical.</p>
<h2>Key Features</h2>
<ul>
<li>Polarized retroreflective detection mode with extended sensing range</li>
<li>EZ BEAM technology eliminates constant mechanical adjustments</li>
<li>Dual LED indicators provide real-time operational feedback</li>
<li>High excess gain improves detection of low-reflectivity objects</li>
<li>Compact, rectangular housing design for space-constrained installations</li>
<li>Light Operate and Dark Operate modes for application flexibility</li>
<li>Durable epoxy-encapsulated construction for harsh industrial environments</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Detection Type:</strong> Polarized Retroreflective</li>
<li><strong>Sensor Style:</strong> Rectangular, self-contained</li>
<li><strong>Light Source:</strong> Infrared (IR)</li>
<li><strong>Detection Range:</strong> Up to 2000 mm (2 meters)</li>
<li><strong>Output Type:</strong> Solid-state switch</li>
<li><strong>Switching Modes:</strong> Light Operate / Dark Operate</li>
<li><strong>Housing:</strong> Epoxy encapsulated thermoplastic with acrylic lens</li>
<li><strong>Indicators:</strong> Dual LED (power and output status)</li>
<li><strong>Connector:</strong> Micro Integral QD</li>
<li><strong>Operating Temperature:</strong> -10°C to +55°C (typical for Q25 series)</li>
</ul>
<h2>Typical Applications</h2>
<p>The Banner Q25AW3LPQ1 is widely used in:</p>
<ul>
<li>Conveyor belt monitoring and product detection</li>
<li>Packaging line item counting and position sensing</li>
<li>Material handling systems and automated sorting</li>
<li>Bottle, carton, and container detection</li>
<li>Presence/absence verification in production lines</li>
<li>Fixed-field industrial automation environments</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Standard PLC digital input modules (24 VDC logic)</li>
<li>Industrial control systems with solid-state switch interfaces</li>
<li>Conveyor control and packaging equipment</li>
<li>Material handling automation systems</li>
<li>Standard industrial electrical cabinets and terminal blocks</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<p>The Banner Q25AW3LPQ1 is a direct replacement for other Q25-series retroreflective sensors with similar specifications. For specific cross-reference information, verify compatibility with your system integrator or Banner technical support before ordering.</p>
<h3>Works With</h3>
<ul>
<li>Banner reflectors and retroreflective tape targets</li>
<li>Standard 24 VDC industrial power supplies</li>
<li>Allen-Bradley, Siemens, Mitsubishi, Omron, and other major PLC brands</li>
<li>Discrete wiring and hardwired control circuits</li>
<li>Industrial automation software and SCADA systems</li>
</ul>
