Overview
The Banner LSR-64 shift register is a discrete industrial output module that extends PLC control by providing synchronized, cascadable outputs for conveyor systems and material handling equipment. This 64-bit shift register module uses an 8-pin interface and is rated for 150mA maximum output per channel, making it suitable for driving solenoids, indicators, and low-power actuators in high-speed production lines.
Key Features
- 64-bit shift register architecture for cascadable output expansion
- 8-pin DIP configuration for board-level integration
- 150mA maximum output rating per stage
- Designed for conveyor and material handling automation
- Compact form factor for space-constrained control cabinets
- Direct PLC connectivity for synchronous output sequencing
Technical Specifications
- Part Number: LSR-64
- Bit Width: 64-bit
- Pin Configuration: 8-pin DIP
- Maximum Output Current: 150mA
- Module Type: Shift Register Output Module
- Manufacturer: Banner Engineering
- Application: Conveyor control and discrete output expansion
Typical Applications
The Banner LSR-64 is ideal for applications requiring synchronized multi-point output control:
- Conveyor belt position sensing and control
- Sequential solenoid or valve actuation in assembly lines
- Multi-stage product sorting and diverting systems
- Discrete indicator and status lamp control
- PLC output expansion in space-limited installations
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix PLC systems
- Siemens S7-200/S7-1200 controllers
- Mitsubishi FX and Q-series PLCs
- Omron CJ and CP-series controllers
- Standard 24VDC industrial control systems
- Board-level integration in industrial control panels
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The LSR-64 is a legacy shift register module; consult manufacturer documentation or contact our sales team for confirmed replacement compatibility with your specific PLC model and version.
