The Babbitt International Nordson 224413 Level Switch PC Board LS8000/R Rev 4 is a remote-mounted radio frequency (RF) level switch designed for applications where it is unsafe or impractical to mount electronics directly to the probe. This advanced system offers precise level detection for a wide range of materials, including dry powders, liquids, and interfaces between immiscible liquids.

Key Features

• Remote Electronics: The receiver board can be installed up to a mile away from the probe, facilitating flexible and safe installation in challenging environments.
• High Sensitivity: Ultra-high sensitivity adjustments allow for the detection of even the driest powders, fines, and flakes, making it suitable for materials such as dry herbicides, plastic pellets, wood chips, and fly ash.
• Solid-State Design: With no moving parts, the LS8000/R serves as a reliable replacement for mechanical devices like floats and rotating paddles, reducing maintenance needs.
• Built-in Time Delay: User-programmable time delay settings help prevent false switching during filling operations or in turbulent conditions, enhancing operational accuracy.
• Explosion-Proof Housing: The cast aluminum enclosure is rated for hazardous areas, ensuring safe operation in environments with explosive gases or dust.
• Static Protection: Integrated static suppression circuitry protects against static buildup, which is particularly beneficial when handling materials prone to generating static electricity.

Specifications

• Power Supply: Standard 115 Vac (±15%) 50/60 Hz, 2 Watts; optional 12 Vdc, 24 Vdc, or 230 Vac.
• Output: Dual Form C Contact DPDT Relay, rated at 5 A resistive at 125/230 Vac or 30 Vdc.
• On-Board Fuse: 250 mA for circuit protection.
• Failsafe Operation: Selectable high or low level settings to suit various application requirements.
• Time Delay: Adjustable from 1/8 second to 2 hours, with selectable ON/OFF delay modes.
• RF Frequency: Approximately 1.3 MHz for reliable level detection.
• Temperature Range: Teflon insulator rated from -30°F to 450°F (-34°C to 232°C).
• Pressure Rating: 300 psi at 75°F (21°C); higher ratings available upon request.
• Enclosure: Cast aluminum, explosion-proof, suitable for Class I, Groups C & D, and Class II, Groups E, F & G hazardous areas.

Applications

• High or low-level alarms in storage tanks and silos.
• Automatic tank filling systems.
• Sump control operations.
• Oil/water interface detection.
• Dry pump protection.

The LS8000/R is versatile and can be used with various materials, including:

• Waste and wastewater.
• Acids and caustics.
• Fuels and oils.
• Slurries.
• Flour and grains.
• Powders.
• Plastics.
• Sand and cement.
• Wood chips.
• Fly ash.
• Oil/water mixtures.
• Foam/liquid interfaces.

With its robust design and advanced features, the Babbitt International Nordson 224413 Level Switch PC Board LS8000/R Rev 4 provides reliable and accurate level measurement solutions for a wide array of industrial applications.
