Overview
The Arrow Hart NEMA 6-30 plug is an industrial-grade straight blade connector designed for 30A 250V AC applications. This 2-pole, 3-wire grounding plug combines robust nylon construction with proven electrical performance, making it a trusted choice for commercial and industrial power distribution. Arrow Hart (now part of Eaton) is renowned for manufacturing wiring devices that meet or exceed UL and CSA standards.
Key Features
- Heavy-duty nylon shell and body construction for durability in industrial environments
- Double dovetail cord clamps with reversible inserts for secure cord retention over multiple cable diameters
- 2-pole, 3-wire grounding configuration for added electrical safety
- Back wiring terminal design for straightforward installation
- Tin-plated bronze contacts for reliable electrical connection
- Ergonomic design for comfortable handling and secure grip
Technical Specifications
- Voltage Rating: 250V AC
- Current Rating: 30A
- Configuration: 2-Pole, 3-Wire Grounding
- NEMA Standard: NEMA 6-30P
- Wire Gauge: 14–8 AWG
- Cord Grip Range: 0.38 to 1.0 inch diameter
- Contact Material: Tin-plated bronze
- Housing Material: Nylon
- Temperature Rating: –40 to 60°C
- Dielectric Strength: 1,000V
- Certifications: UL498, CSA C22.2 No. 42
Typical Applications
- Heavy-duty industrial machinery and equipment requiring 30A 250V power
- Commercial HVAC and climate control systems
- Manufacturing and processing facilities
- Welding and metal fabrication equipment
- High-amperage stationary equipment power distribution
- Construction site temporary power distribution
Compatibility & Replacements
Compatible With
- NEMA 6-30R receptacles and inlets
- Industrial 30A 250V AC power distribution systems
- Equipment requiring IEC 60309 compliance
- Standard North American industrial electrical installations
Replaces / Drop-In Replacement For
- Arrow Hart model 5701N straight blade plug NEMA 6-30P
- Previous Arrow Hart NEMA 6-30 straight blade connector designs
- OEM replacement for equipment originally shipped with Arrow Hart 6-30 plugs
Works With
- NEMA 6-30R industrial receptacles and power inlets
- Heavy-duty flexible power cords (14–8 AWG)
- Industrial electrical control panels and distribution systems
- Equipment with UL498 or CSA-certified power inputs
