Overview
The APFEL CM64acR-2 is a legacy industrial printed circuit board featuring a 64-way DIN41612 right-angle connector. Built to European industrial standards, this component is commonly integrated into control systems, instrumentation panels, and modular automation chassis. The board supports both A and C row loading configurations, making it suitable for signal distribution and I/O interconnection in legacy systems.
Key Features
- 64-way DIN41612 connector with right-angle orientation
- Rows A and C loaded for dual-channel signal routing
- 2.54mm pitch spacing for standard industrial PCB compatibility
- Solder-pin terminal construction for secure mechanical and electrical connection
- Glass-filled PBT material with UL 94V-0 flame rating
- Gold-plated brass contacts for corrosion resistance
Technical Specifications
- Connector Type: DIN41612 64-way, 3-row format
- Pitch: 2.54mm
- Rows Loaded: A and C
- Current Rating: 2A per contact
- Contact Material: Brass with gold plating
- Dielectric Voltage: 1000 Vac withstanding
- Contact Resistance: 30mR maximum
- Operating Temperature: –55°C to +105°C
- Insulation Material: Glass-filled PBT UL 94V-0
- Origin: Taiwan
- Certifications: UL, cUL listing
- Mounting: Right-angle PCB plug
Typical Applications
The APFEL CM64acR-2 is commonly used in:
- Industrial process control panels and PLC enclosures
- Modular instrumentation systems and test equipment
- Signal distribution boards in automation cabinets
- Legacy motion control and Focus II systems
- High-density I/O interconnection in manufacturing systems
Compatibility & Replacements
Compatible With
- DIN41612 female connectors (3-row C-type configurations)
- Standard Eurocard enclosure systems
- Industrial control systems using 64-pin connector standards
- Legacy APFEL LDS Focus II systems and modules
- Systems requiring –55°C to +105°C temperature operation
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This is a specialized component; confirm that the specific circuit board variant and pin configuration match your legacy system requirements.
Works With
- DIN41612 female 9001-1296, 1264 C-type connectors
- 9001-1496, 1464 R-type receptacles
- 9001-1264 IDC-type connectors
- Standard industrial PCB mounting and soldering processes
- Industrial automation and process control equipment
