Overview
The Ametek 80485SE Rev H is a precision oxygen sensor board assembly engineered for industrial oxygen measurement and gas analysis applications. This PCB assembly supports 240V full-wave operation, delivering reliable sensor control for continuous monitoring environments. The Rev H revision represents the latest design iteration with proven performance in field-critical applications.
Key Features
- 240V Full-Wave Operation: Robust power handling for consistent sensor excitation
- Rev H Design: Latest revision with manufacturing improvements and stability enhancements
- Oxygen Measurement: Purpose-built for O2 sensor signal conditioning and analysis
- Industrial-Grade Electronics: Designed for manufacturing, refining, and analytical instrument applications
- PCB Assembly Format: Direct replacement for legacy oxygen analyzer systems
Technical Specifications
The following specifications have been verified from manufacturer documentation:
- Input Voltage: 240V AC
- Configuration: Full-wave rectification
- Part Number: Ametek 80485SE
- Revision: Rev H
- Product Type: PCB Sensor Assembly
- Application Class: Oxygen analysis and measurement
- Industry Standard: Compatible with Ametek oxygen analyzer platforms
Typical Applications
The Ametek 80485SE oxygen sensor board is commonly deployed in:
- Oxygen analyzers and gas measurement instruments
- Industrial process monitoring and control systems
- Combustion efficiency measurement in furnaces and boilers
- Laboratory and analytical instrumentation
- Refinery and petrochemical process control
- Retrofit and upgrade projects for legacy gas analysis equipment
Compatibility & Replacements
Compatible With
- Ametek oxygen analyzer platforms and instrumentation
- Industrial gas analysis systems requiring O2 sensor boards
- Systems originally equipped with Ametek 80485SE boards (all revisions)
- 240V AC power supplies and control systems
Replaces / Drop-In Replacement For
The Ametek 80485SE Rev H directly replaces earlier revisions of the same board (Rev G, Rev E, and earlier) in compatible oxygen analyzer systems. When substituting in your equipment, verify that your instrument documentation explicitly supports Rev H compatibility. Consult your system manual or contact Ametek technical support to confirm drop-in replacement eligibility.
Works With
- Ametek oxygen measurement instrument families
- Industrial oxygen analyzer control panels
- 240V AC electrical distribution systems
- Zirconium-based and other O2 sensor probe designs (system-dependent)
